30564 - Toro 62" Walk-Behind Mower (SN: 000800001 - 000899999) (1988) ENGINE, ONAN MODEL NO. B48G-GA020 TYPE NO. 4348G STARTER MOTOR Parts Diagram

62" Walk-Behind Mower

ENGINE, ONAN MODEL NO. B48G-GA020 TYPE NO. 4348G STARTER MOTOR Parts Diagram

  • Title
1

Screw-Solenoid

$

$

Not available

2

Washer

$

$

Not available

3

Ring-Pinion Retainer

$

$

Not available

4

Collar-Pinion Stop

$

$

Not available

5

Lever-Shift

$

$

Not available

6

Plate-Wear

$

$

Not available

7

Plug-Rubber

$

$

Not available

Toro 62-2770

Starter Shift Lever Kit (Incl. Ref. #5-7)

$

$

Not available

8

Toro 62-2720

Starter Solenoid Kit
(Superseded to 72-3930)

$

$

Not available

9

Shim-Armature

$

$

Not available

10

Toro 62-2750

Brush Mounting Kit
(Superseded to 62-2740)

$

$

Not available

11

Bolt

$

$

Not available

12

Cap Assembly

$

$

Not available

Toro 62-2730

Bushing Kit (Incl. Ref. #12, 13 & 17)

$

$

Not available

14

Screw-Brush Holder

$

$

Not available

Toro 62-2760

Hardware Kit (Incl. Ref. #1-4, 9, 11 & 14)

$

$

Not available

15

Brush-Positive

$

$

Not available

Toro 62-2740

Starter Brush Kit (Incl. Ref. #15)

$

$

Not available

16

Starter Clutch Assembly

$

$

Not available

18

Toro 57-6390

NUT-JAM

$1.49

$

Usually ships in 3-6 days
