270-V0 - Troy-Bilt Engine 270-V0 Cylinder Head Parts Diagram

Engine

270-V0 Cylinder Head Parts Diagram

  • Title

1

Troy-Bilt 710-04968

Bolt M6×16

$6.99

$

In Stock, only 3 left!

0

2

Troy-Bilt 951-11054

Valve Cover
(Superseded to 951-11054B)

$15.99

$

Usually ships in 3-6 days

0

3

Troy-Bilt 731-07059

Breather Hose

$6.49

$

In Stock, only 1 left!

0

3a

Troy-Bilt 726-04101

Hose Clamp

$4.49

$

Usually ships in 3-6 days

0

4

Troy-Bilt 951-11565

Valve Cover Gasket
(Superseded to 751P11565B)

$10.99

$

In Stock, Qty 12

0

5

Troy-Bilt 951-11892

Rocker Arm Assembly

$40.99

$

Usually ships in 3-6 days

0

6

Troy-Bilt 751-11124

Nut, Pivot Locking

$9.49

$

In Stock, only 2 left!

0

7

Troy-Bilt 751-11123

Adjusting Nut , Valve

$10.99

$

In Stock, only 4 left!

0

8

Troy-Bilt 951-11893

Rocker Arm

$7.99

$

Usually ships in 3-6 days

0

9

Troy-Bilt 710-04902

Bolt, Pivot

$6.99

$

In Stock, only 4 left!

0

10

Troy-Bilt 951-11895

Push Rod Guide

$8.99

$

Usually ships in 3-6 days

0

11

Troy-Bilt 951-12000

Retainer, In.Valve Spring

$4.49

$

In Stock, only 1 left!

0

12

Troy-Bilt 951-12002

Adjuster, Exh Valve
(Superseded to 751P12002A)

$2.99

$

Usually ships in 3-6 days

0

13

Troy-Bilt 951-12003

Retainer, Ex.Valve Spring

$4.49

$

In Stock, only 1 left!

0

14

Troy-Bilt 951-12004

Valve Spring
(Superseded to 751P12004A)

$1.99

$

In Stock, Qty 5

0

15

Troy-Bilt 951-11894

Intake Valve Seal

$10.99

$

Usually ships in 3-6 days

0

16

Troy-Bilt 710-04933

Bolt M8×55

$3.99

$

In Stock, Qty 10

0

17

Troy-Bilt 951-10799

Cylinder Head Assembly

Note: (Incl. 4, 6-10, 12-17, 20, 25, 26, 38, 41-43)

$176.99

$

Usually ships in 3-6 days

0

18

Troy-Bilt 951-10292

Spark Plug
(Superseded to 951-10292A)

$6.99

$

In Stock, Qty 20+

0

38

Troy-Bilt 951-11572

Gasket, Cylinder Head

$11.99

$

In Stock, Qty 15

0

39

Troy-Bilt 951-10648

Push Rod Kit

$17.99

$

In Stock, only 3 left!

0

40

Troy-Bilt 951-11899

Tappet

$8.49

$

In Stock, only 4 left!

0

41

Troy-Bilt 715-04090

Dowel Pin 10×16
(Superseded to 715-04108)

$4.49

$

In Stock, only 3 left!

0

42

Troy-Bilt 951-10647A

Valve Kit

$64.99

$

Usually ships in 3-6 days

0

43

Troy-Bilt 951-10647A

Valve Kit

$64.99

$

Usually ships in 3-6 days

0

118

Troy-Bilt 951-11063

Valve Cover Kit
(Superseded to 951-12626)

$28.99

$

Usually ships in 3-6 days

0

Troy-Bilt 951-10819

Cylinder Head Service Kit

Note: Not shown (Incl. 4, 15, 16, 38)

$19.99

$

Usually ships in 3-6 days

0

Troy-Bilt 951-12120

Gasket Kit - - External

Note: Not shown (Incl. 2, 4, 25-27, 29, 68)

$

$

Not available

Troy-Bilt 951-12121

Gasket Kit Complete
(Superseded to 951-12121A)

Note: Not shown (Incl. 4, 20, 25-27, 29, 38, 52, 53, 62, 66, 68, 70)

$58.99

$

Usually ships in 3-6 days

0
