2690444 - Simplicity Citation 48" Zero-Turn Mower, 21hp Briggs & Stratton Rear Bumper Group - 48" Models & 52" Models S/N: 2014624505 & Below Parts Diagram

Citation 48" Zero-Turn Mower, 21hp Briggs & Stratton

Rear Bumper Group - 48" Models & 52" Models S/N: 2014624505 & Below Parts Diagram

  • Title

1

MAIN FRAME

$

$

Not available

2

Simplicity 5401174C

HEAT SHIELD
(Superseded to 5401174CSM)

$44.99

$

Usually ships in 2-12 days

0

3

Simplicity 5403268C

BUMPER
(Superseded to 5403268CSM)

$353.99

$

Usually ships in 2-12 days

0

4

Simplicity 5410295A

PLATE, SEAT BELT ANCHOR - BLK
(Superseded to 5410295AYP)

$7.49

$

Usually ships in 2-12 days

0

5

Simplicity 5400847A

MOUNT, SEAT BELT - RH - BLK

$

$

Not available

6

Simplicity 5025158

WASHER, 1/2 SAE
(Superseded to 5025158SM)

$3.99

$

In Stock, Qty 12

0

7

Simplicity 5025396

NUT, 1/2-13 HEX NYLOCK FLANGE
(Superseded to 770225)

$3.49

$

In Stock, Qty 20+

0

8

Simplicity 5025017X26

BOLT, 1/2-13 X 3-1/4" GD5
(Superseded to 5025017X26SM)

$5.49

$

In Stock, only 2 left!

0

9

Simplicity 5061725C

CARB PROTECTOR PLATE
(Superseded to 5061725CSM)

$33.99

$

Usually ships in 2-12 days

0

10

Simplicity 5023484

PLUG, PANEL, 1.25 BLACK
(Superseded to 5023484SM)

$3.99

$

In Stock, Qty 20+

0

11

ROLL BAR TOP LOOP

$

$

Not available

12

ROLL BAR POST, RH

$

$

Not available

13

ROLL BAR POST, LH

$

$

Not available

14

Simplicity 5025156

WASHER, 3/8 SAE
(Superseded to 5025156FS)

$3.49

$

Usually ships in 2-12 days

0

15

Simplicity 5025013X8

BOLT, 3/8-16 X 1" GD5
(Superseded to 5025013X8SM)

$3.99

$

In Stock, Qty 6

0

16

Simplicity 5025394

NUT, 3/8-16 X 1" GD5
(Superseded to 5025394SM)

$4.49

$

In Stock, Qty 20+

0

17

Simplicity 5025011X6

BOLT, 5/16-18 X 3/4 GD5
(Superseded to 5025011X6SM)

$3.99

$

In Stock, only 4 left!

0

18

Simplicity 5025392

NUT, 5/16-18 HEX NYLOCK FLANGE
(Superseded to 5025392FS)

$3.49

$

Usually ships in 2-12 days

0

19

Simplicity 5025017X14

BOLT, 1/2-13 X 1-3/4 GD5 YZ
(Superseded to 5025017X14YP)

$3.49

$

In Stock, only 4 left!

0

20

Simplicity 5025396

NUT, 1/2-13 HEX NYLOCK FLANGE
(Superseded to 770225)

$3.49

$

In Stock, Qty 20+

0

21

Simplicity 5100139

SEAT BELT ASSEMBLY, STANDARD
(Superseded to 5100139SM)

$103.99

$

Usually ships in 2-12 days

0

21

Simplicity 5100397

SEAT BELT ASSEMBLY, EXTRA LONG
(Superseded to 5100397SM)

$122.99

$

Usually ships in 2-12 days

0

22

Simplicity 5100377

ROLL BAR HARDWARE BAG
(Superseded to 5100377SM)

$83.99

$

Usually ships in 2-12 days

0

23

Simplicity 5100079

PIN, HITCH, BLACK W/ PLASTIC LANYARD
(Superseded to 5100079SM)

$35.99

$

Usually ships in 2-12 days

0

24

Simplicity 5100383

RUBBER BUMPER
(Superseded to 5100383SM)

$3.99

$

In Stock, only 2 left!

0

25

Simplicity 5100267

SCREW, 1/2-13 X 1.00, SHCS
(Superseded to 5100267SM)

$3.49

$

Usually ships in 2-12 days

0

26

*BOLT

$

$

Not available

27

*NUT

$

$

Not available

28

ROPS (Call 1-800-933-6175 x708 if replacing a ROPS)

$

$

Not available

29

Simplicity 5025155

WASHER, 5/16" SAE

$

$

Currently unavailable

30

Simplicity 5045178

SPACER, .52 X 1.00 X .75
(Superseded to 5045178SM)

$7.49

$

In Stock, Qty 6

0

31

Simplicity 5100520

SPACER, .515 X 1.00 X .218
(Superseded to 5100520SM)

$6.49

$

In Stock, only 2 left!

0

32

Simplicity 5101049

CAP, VINYL
(Superseded to 5101049SM)

$2.99

$

Usually ships in 2-12 days

0

33

Simplicity 5100545

RUBBER WASHER
(Superseded to 5100545SM)

Note: (Not shown)

$4.99

$

Usually ships in 2-12 days

0
