Craftsman 247.270220 (13A-344-099) - Craftsman Lawn Tractor (2003) (Sears) Deck Stabilizer Assembly Parts Lookup with Diagrams

1

MTD 683-0142-0637

No Longer Available PIVOT BAR - POWDER BLACK (0637)

Variations

MTD 683-0142-0637

No Longer Available PIVOT BAR - POWDER BLACK (0637)

$

Not available 

MTD 683-0142-0665

No Longer Available PIVOT BAR - YARDMAN GREEN (0665)

$

Not available 

$

Not available 

2

MTD 683-0160

Bracket Assembly: Hood Pivot

$

Not available 

3

MTD 683-0163A-0637

Steering Support Bracket - POWDER BLACK (0637)

Variations

MTD 683-0163A-0637

Steering Support Bracket - POWDER BLACK (0637)

$

Not available 

$

Not available 

4

MTD 683-0264A-0637

CHANNEL ASM-FRONT - POWDER BLACK (0637)

(Superseded to 683-0264A-0637) 

Variations

MTD 683-0264A-0637

CHANNEL ASM-FRONT - POWDER BLACK (0637)

$147.99

$

Usually ships in 3-6 days

$147.99

$

Usually ships in 3-6 days

5

MTD 710-0599

TT screw 1/4-20 x 0.5"

$4.49

$

In Stock, Qty 20+

6

MTD 710-1017

AB Screw 1/4-14 x 0.625"

$8.49

$

In Stock, Qty 16

7

MTD 710-1611B

TT Screw 5/16-18 x 0.75"

$6.99

$

Usually ships in 3-6 days

8

MTD 711-0332

Clevis Pin

(Superseded to 911-0332) 

$16.99

$

In Stock, Qty 20+

9

MTD 711-1165

Clevis Pin

$13.99

$

Usually ships in 3-6 days

10

MTD 714-0104

Cotter Pin

$4.49

$

In Stock, Qty 20+

11

MTD 714-0147

Hairpin Clip

$4.99

$

In Stock, Qty 6

12

MTD 714-0470

Cotter Pin

$4.49

$

In Stock, Qty 20+

13

MTD 725-0157

Cable Tie

$3.99

$

In Stock, Qty 20+

14

MTD 732-0829

Extension Spring

(Superseded to 932-0829) 

$

Not available 

15

MTD 735-0199A

Rubber Bumper

$7.99

$

In Stock, Qty 20+

16

MTD 735-0271

Bumper

(Superseded to 735-0271A) 

$8.99

$

In Stock, Qty 20+

17

MTD 736-0101

Flat Washer

(Superseded to 936-0101) 

$4.99

$

Usually ships in 3-6 days

18

MTD 736-0187

Flat Washer

$4.49

$

In Stock, Qty 20+

19

MTD 736-0275

Flat Washer

$6.99

$

Usually ships in 3-6 days

20

MTD 736-3019

Flat Washer

$5.99

$

In Stock, Qty 9

21

MTD 747-0985

Deck Rod

$

Not available 

22

MTD 783-04231-0637

No Longer Available - POWDER BLACK (0637)

Variations

MTD 783-04231-0637

No Longer Available - POWDER BLACK (0637)

$

Not available 

MTD 783-04231-0638

RAIL-FRAME REAR - MTD/TROY-BILT RED (0638)

$

Not available 

MTD 783-04231-0650

No Longer Available RAIL-FRAME - RED METALLIC (0650)

$

Not available 

MTD 783-04231-0674

No Longer Available - YARDMAN YELLOW (0674)

$

Not available 

MTD 783-04231-0721

RAIL-FRAME REAR - SEARS RED (0721)

$

Not available 

MTD 783-04231-4044

RAIL-FRAME REAR - CRAFTSMAN RED (4044)

$

Not available 

$

Not available 

23

MTD 783-04248-0637

No Longer Available RAIL-FRAME - POWDER BLACK (0637)

Variations

MTD 783-04248-0637

No Longer Available RAIL-FRAME - POWDER BLACK (0637)

$

Not available 

MTD 783-04248-0638

No Longer Available RAIL-FRAME - MTD/TROY-BILT RED (0638)

$

Not available 

MTD 783-04248-0650

No Longer Available RAIL-FRAME - RED METALLIC (0650)

$

Not available 

MTD 783-04248-0674

No Longer Available RAIL-FRAME - YARDMAN YELLOW (0674)

$

Not available 

MTD 783-04248-0721

No Longer Available RAIL-FRAME - SEARS RED (0721)

$

Not available 

MTD 783-04248-4044

No Longer Available RAIL-FRAME - CRAFTSMAN RED (4044)

$

Not available 

$

Not available 

24

MTD 783-04252-0637

RAIL-FRAME LH - POWDER BLACK (0637)

Variations

MTD 783-04252-0637

RAIL-FRAME LH - POWDER BLACK (0637)

$

Not available 

MTD 783-04252-0638

No Longer Available - MTD/TROY-BILT RED (0638)

$

Not available 

MTD 783-04252-0650

No Longer Available RAIL-FRAME - RED METALLIC (0650)

$

Not available 

MTD 783-04252-0674

RAIL-FRAME LH - YARDMAN YELLOW (0674)

$

Not available 

MTD 783-04252-0721

RAIL-FRAME LH - SEARS RED (0721)

$

Not available 

MTD 783-04252-4044

RAIL-FRAME LH - CRAFTSMAN RED (4044)

$

Not available 

$

Not available 

25

MTD 783-0554-0637

No Longer Available BRACKET-CAM - POWDER BLACK (0637)

Variations

MTD 783-0554-0637

No Longer Available BRACKET-CAM - POWDER BLACK (0637)

$

Not available 

MTD 783-0554-0665

No Longer Available BRACKET-CA - YARDMAN GREEN (0665)

$

Not available 

$

Not available 

26

MTD 783-0564A-0498

No Longer Available FRAME-UPPE - OLD CUB YELLOW (0498)

Variations

MTD 783-0564A-0498

No Longer Available FRAME-UPPE - OLD CUB YELLOW (0498)

$

Not available 

MTD 783-0564A-0637

No Longer Available FRAME-UPPE - POWDER BLACK (0637)

$

Not available 

MTD 783-0564A-0648

No Longer Available FRAME-UPPE - TECH GRAY (0648)

$

Not available 

MTD 783-0564A-0650

No Longer Available FRAME-UPPE - RED METALLIC (0650)

$

Not available 

MTD 783-0564A-0674

No Longer Available - YARDMAN YELLOW (0674)

$

Not available 

MTD 783-0564A-0716

No Longer Available FRAME-UPPE - CUB YELLOW-99 (0716)

$

Not available 

$

Not available 

27

MTD 783-0605-0637

BRACKET-STABILIZER - POWDER BLACK (0637)

(Superseded to 783-0605-0637) 

Variations

MTD 783-0605-0637

BRACKET-STABILIZER - POWDER BLACK (0637)

$

Not available 

$

Not available 

28

MTD 783-0811A-0637

COVER STEERING - POWDER BLACK (0637)

Variations

MTD 783-0811A-0637

COVER STEERING - POWDER BLACK (0637)

$

Not available 

MTD 783-0811A-0498

No Longer Available COVER STEE - OLD CUB YELLOW (0498)

$

Not available 

MTD 783-0811A-0638

No Longer Available COVER STEE - MTD/TROY-BILT RED (0638)

$

Not available 

MTD 783-0811A-0648

No Longer Available COVER STEE - TECH GRAY (0648)

$

Not available 

MTD 783-0811A-0650

No Longer Available COVER STEE - RED METALLIC (0650)

$

Not available 

MTD 783-0811A-0665

No Longer Available COVER STEE - YARDMAN GREEN (0665)

$

Not available 

MTD 783-0811A-0716

COVER STEERING - CUB YELLOW-99 (0716)

$

Not available 

$

Not available 

247.270220 (13A-344-099) - Craftsman Lawn Tractor (2003) (Sears) Deck Stabilizer Assembly Parts Diagram
