23510 - Toro 20" Turf Seeder (SN: 314000001 - 314999999) (2014) CUTTING WHEEL ASSEMBLY Parts Diagram

20" Turf Seeder

CUTTING WHEEL ASSEMBLY Parts Diagram

  • Title

1

Toro 116-9932-03

HANDLE-HEIGHT

$129.99

$

Usually ships in 3-6 days

0

2

Toro 98-4799

Spacer

$8.49

$

In Stock, Qty 20+

0

3

Toro 116-9928

PLATE-HEIGHT

$21.99

$

Usually ships in 3-6 days

0

4

Toro 126-0010-03

PIVOT-HEIGHT

$120.99

$

Usually ships in 3-6 days

0

5

Toro 126-2446

DECAL-CUT DEPTH, SLICER/SEEDER

$13.99

$

Usually ships in 3-6 days

0

6

Toro 121-1961

BEARING

$42.99

$

In Stock, only 4 left!

0

12

Toro 3230-16

Bolt-Carriage 5/16-18 x 7/8

$2.99

$

In Stock, Qty 20+

0

13

Toro 3296-47

Nut-Nyloc 5/16-18 Thin

$4.49

$

In Stock, Qty 20+

0

14

Toro 322-2

Screw-HH 5/16-18 x 5/8

$2.99

$

In Stock, Qty 20+

0

15

Toro 603164

NUT-BLADE
(Superseded to 121-3611)

$5.99

$

In Stock, Qty 9

0

16

Toro 104-7201

Nut-Nyloc 1/4-20 Flg

$1.49

$

In Stock, Qty 20+

0

19

Toro 116-9992

BEARING-FLANGE

$45.99

$

Usually ships in 3-6 days

0

20

Toro 321-8

Screw-HH 1/4-20 x 1 1/4

$3.99

$

In Stock, Qty 15

0

24

Toro 3257-5

Key-Woodruff #9 3/4 x 3/16

$5.99

$

In Stock, Qty 19

0

25

Toro 107-1664

LEVER ASM

$79.99

$

Usually ships in 3-6 days

0

25:1

Toro 106-3239

Screw-Lock

$55.99

$

Usually ships in 3-6 days

0

25:2

Toro 107-1644

CAP-LOCK

$41.99

$

In Stock, only 2 left!

0

25:3

Toro 106-3241

Lever-Lock
(Superseded to 107-1664)

$79.99

$

Usually ships in 3-6 days

0

25:4

Toro 3296-29

Nut-Nyloc 5/16-18

$2.49

$

In Stock, Qty 20+

0

26

Toro 86-1990

Washer

$3.99

$

In Stock, Qty 15

0

27

Toro 3296-23

Nut-Nyloc 1/2-13

$1.49

$

In Stock, Qty 20+

0

28

Toro 126-0034

SLICER SHAFT ASM

$568.99

$

Usually ships in 3-6 days

0

29

Toro 302-19

Zerk-1/4-28 Str

Note: Use Pro-Lock, Nut Type (P/N 1-840022, .5ml tube) on threads.

$2.49

$

In Stock, Qty 20+

0

30

Toro 3245-35

Screw-Set HSH 1/4-28 X 1/4

Note: Use Pro-Lock, Nut Type (P/N 1-840022, .5ml tube) on threads.

$0.99

$

In Stock, Qty 10

0
