21738 - Toro Whirlwind Walk-Behind Mower (SN: 008000001 - 008999999) (1978) HOUSING ASSEMBLY Parts Diagram

Whirlwind Walk-Behind Mower

HOUSING ASSEMBLY Parts Diagram

  • Title
1

Toro 20-4690

TORO LOGO DECAL

$7.99

$

Usually ships in 3-6 days

0

2

Toro 20-4330

Caution Decal

$

$

Not available

3

Toro 20-2800

Deflector Cover Assembly (Incl. Ref. #1-2 & 6)
(Superseded to 13-4049)

$

$

Not available

4

Toro 3256-1

WASHER-FLAT

$0.99

$

In Stock, Qty 20+

0

5

Toro 12-3270

SCREW

$3.49

$

In Stock, Qty 20+

0

6

Toro 20-2640

SPRING HINGE

$

$

Not available

7

Toro 20-2130

Pivot Arm
(Superseded to 98-1527)

$

$

Not available

8

Toro 3-3287

SPACER

$5.49

$

In Stock, Qty 16

0

9

Toro 5-2446

Latch
(Superseded to 43-1550)

$

$

Not available

10

Toro 5-2490

SCREW-SHOULDER

$

$

Not available

11

Toro 6-4500

WASHOUT PLUG

$

$

Not available

12

Toro 12-2080

HANDLE PIVOT NUT

$25.99

$

Usually ships in 3-6 days

0

13

Toro 22-4950

REAR SAFETY SHIELD 21

$

$

Not available

14

Toro 25-7740

KNOB-ARM

$4.99

$

In Stock, Qty 20+

0

15

Toro 33-3201

SHIELD ROD

$

$

Not available

16

Toro 32146-6

Nut
(Superseded to 3296-6)

$1.99

$

In Stock, Qty 20+

0

17

Toro 27-6200

WHEEL TIRE ASM 8 IN

$

$

Not available

18

Toro 27-6230

BOLT-WHEEL

$8.49

$

In Stock, only 1 left!

0

19

Toro 3-0655

5/16-18 PIVOT SCREW

$15.99

$

In Stock, only 1 left!

0

20

Toro 20-2140

Pivot Arm
(Superseded to 98-1511)

$

$

Not available

21

Toro 25-8000

SPRING ARM ASM

$

$

Not available

22

Toro 5-4460

WASHER-PIVOT

$7.99

$

In Stock, Qty 20+

0

23

Toro 21-5580

DRIVER PULLEY

$

$

Not available

24

Toro 5-4769

Muffler Assembly (Incl. Ref. #25 & 26)

$62.99

$

Usually ships in 3-6 days

0

Toro 36-3200

Muffler (Spark Arrestor-Optional)
(Superseded to 39-5930)

Note: Not illustrated

$

$

Not available

25

Toro 321-20

SCREW-HH

$7.49

$

Usually ships in 3-6 days

0

26

Toro 3-5094

CLIP - LOCKING

$11.99

$

Usually ships in 3-6 days

0

27

Toro 20-2720

Blade
(Superseded to 20-2720-03)

$41.99

$

In Stock, only 2 left!

0

28

Toro 20-2750

Blade Retailer
(Superseded to 49-7890)

$

$

Not available

29

Toro 3-5246

SPECIAL SCREW

$

$

Not available

30

Toro 3253-22

WASHER-LOCK

$2.99

$

In Stock, only 3 left!

0

31

Toro 8-4240

AntiScalp Cup
(Superseded to 80-2770)

$17.99

$

Usually ships in 3-6 days

0

32

Toro 27-6300

KEY-SQUARE

$6.49

$

In Stock, only 1 left!

0

33

Toro 8-0649

Housing

$

$

Not available

34

Toro 33-2310

Decal Deck

$

$

Not available

Toro 25-9150

REPLACEMNT SERIAL PLT

Note: Not illustrated

$19.99

$

Usually ships in 3-6 days

0

35

Toro 22-7350

Decal

$

$

Not available
