214 KW (51A-330-195) - MTD Pro Walk-Behind Mower Rear Axle Parts Diagram

Pro Walk-Behind Mower

Rear Axle Parts Diagram

  • Title

1

MTD 712-04065

L-Nut, 3/8-16, NYL INS. GR A.

$3.99

$

In Stock, Qty 20+

0

2

MTD 710-0751

HHCS, 1/4-20, .620, GR5, Standard

$3.99

$

In Stock, Qty 20+

0

3

MTD 01000861

Pivot Wheel Bracket Assembly, 2 POS

$91.99

$

Usually ships in 3-6 days

0

4

MTD 710-0653

Screw, TT, 1/4-20, 0.375, Hex Index Washer

$4.49

$

In Stock, Qty 8

0

5

MTD 710-0599

Screw, TT, 1/4-20, 0.625, PANTRXI

$4.49

$

In Stock, Qty 20+

0

6

MTD 01002828

Rear Axle

$

$

Not available

7

MTD 01000870

Trail Shield

Note: NLA

$

$

Not available

8

MTD 732-0864

Spring Plate Height Adjuster

$

$

Not available

9

MTD 936-0133

Flat Washer, .411 x 1 .25 x .100
(Superseded to 736-0133)

$

$

Not available

10

MTD 936-0160

Flat Washer .536 IDX .781 ODX .01

$4.49

$

In Stock, Qty 9

0

11

MTD 936-0232

Wave Washer .531 IDX .781 ODX .01
(Superseded to 736-0232)

$4.99

$

In Stock, Qty 12

0

12

MTD 01002829

Height Adjustment Handle

Note: NLA

$

$

Not available

13

MTD 01002830

Height Adjustment Bracket, Right Rear

Note: NLA

$

$

Not available

14

MTD 01002831

Height Adjustment Bracket, Left Rear

Note: NLA

$

$

Not available

15

MTD 01002832

Spring Lever Support Bracket

$

$

Not available

16

MTD 912-3027

Nut, 1/4-20, Hex Flange, Lock, Group F

$4.49

$

In Stock, Qty 20+

0
