2107001 - Simplicity Models 41 & 42 Plow Frame & Hitch - 14" Two Bottom Plow Group (3482I87) Parts Diagram

Models 41 & 42 Plow

Frame & Hitch - 14" Two Bottom Plow Group (3482I87) Parts Diagram

  • Title

1

Simplicity 2107079-2

FRAME ASSEMBLY

$

$

Not available

1

Simplicity 0927074-5

SETSCREW, Square Head, Cup Point, 5/8NC x 1-1/4

$

$

Not available

1

Simplicity 0915726-4

NUT, 5/8NC

$

$

Not available

2

Simplicity 2107027-1

BEAM, Stub

$

$

Not available

2

Simplicity 0923111-9

CAPSCREW, 5/8NC x 3

$

$

Not available

2

Simplicity 0917373-3

LOCKWASHER, 5/8

$

$

Not available

2

Simplicity 0915726-4

NUT, 5/8NC

$

$

Not available

3

Simplicity 0925707-2

CAPSCREW, Beam Pivot, 3/4NC x 3

$

$

Not available

3

Simplicity 0913160-8

NUT, 3/4NC

$

$

Not available

4

Simplicity 0923320-6

CAPSCREW, Beam Shear, 1/2NC x 3

$

$

Not available

4

Simplicity 0916966-5

LOCKWASHER, 1/2

$

$

Not available

4

Simplicity 0916951-7

NUT, 1/2NC

$

$

Not available

5

Simplicity 0334357-1

PIN, Link (Cat. l)

$

$

Not available

5

Simplicity 0919426-7

LOCKWASHER, 7/8

$

$

Not available

5

Simplicity 0920747-3

NUT, 7/8NF

$

$

Not available

6

Simplicity 2097978-7

PIN, Hitch, Upper

$

$

Not available

7

Simplicity 0244066-7

PIN, Quick

$

$

Not available

8

Simplicity 2107078-4

BAR, Adjusting

$

$

Not available

8

Simplicity 0924347-8

CAPSCREW, 7/16NC x 3

$

$

Not available

8

Simplicity 0918199-1

LOCKWASHER, 7/16

$

$

Not available

8

Simplicity 0918213-0

NUT, 7/16NC

$

$

Not available

9

Simplicity 0579149-6

DECAL (Allis-Chalmers)

$

$

Not available

10

Simplicity 0593750-3

DECAL (42 Model Identification)

$

$

Not available
