21-12KE03 (312-A) - Toro Garden Tractor (1987) AUTOMATIC TRANSMISSION-300 SERIES Parts Diagram

Garden Tractor

AUTOMATIC TRANSMISSION-300 SERIES Parts Diagram

  • Title

1

Toro 110959

TRANSMISSION HYDRO

$

$

Not available

2

Toro 110945

GEAR 20TEETH DRIVE

$276.99

$

Usually ships in 3-6 days

0

3

Toro 103995

WASHER

$9.49

$

In Stock, only 2 left!

0

4

Toro 908002

H H C S
(Superseded to 321-3)

$1.49

$

In Stock, Qty 20+

0

5

Toro 7951

GASKET HYDRO

$

$

Not available

6

Toro 908143

H H C S
(Superseded to 323-39)

$11.99

$

In Stock, Qty 20+

0

7

Toro 911102

BLT SH 3/8-16X 1 1/4

$

$

Not available

8

Toro 911111

BOLT SH 3/8-16X3 1/2

$

$

Not available

9

Toro 915113

Nut
(Superseded to 32153-2)

$0.99

$

In Stock, Qty 13

0

10

Toro 110948

CONTROL SUPPORT ASSY R

$

$

Not available

11

Toro 110946

ARM SPEED CONTROL

$

$

Not available

12

Toro 937082

KEY WOODR 1/8X1/2 DI

$

$

Not available

13

Toro 920009

Washer
(Superseded to 3256-24)

$0.99

$

In Stock, Qty 20+

0

14

Toro 915663

NUT
(Superseded to 3296-39)

$2.99

$

In Stock, Qty 20+

0

15

Toro 108326

SPACER-PIVOT

$23.99

$

Usually ships in 3-6 days

0

16

Toro 108327

SPACER-FRICTION

$2.99

$

Usually ships in 3-6 days

0

17

Toro 100365

WASHER-SPRING DISC

$

$

Not available

18

Toro 100305

FRICTION WASHER

$5.99

$

In Stock, only 2 left!

0

19

Toro 108333

CAM-SPEED CONTROL (NS)

$43.99

$

In Stock, only 1 left!

0

20

Toro 100309

CAM-SPACER

$9.99

$

In Stock, only 1 left!

0

21

Toro 108881

NUT

$6.49

$

In Stock, only 2 left!

0

22

Toro 106661

CAM

$

$

Not available

23

Toro 908021

Bolt
(Superseded to 322-7)

$1.49

$

In Stock, Qty 20+

0

24

Toro 110953

ADAPTER-HYDRO

$

$

Not available

25

Toro 108319

GASKET

$10.99

$

In Stock, only 2 left!

0

26

Toro 110938

SPACER CAM

$

$

Not available

27

Toro 104904

Plug Fitting w/O-ring
(Superseded to 102613)

$

$

Not available

28

Toro 110952

Tank Assembly(Includes elbow & rubber bushing)

$

$

Not available

29

Toro 111319

Hose
(Superseded to 101338)

$

$

Not available

30

Toro 111313

FITTING-ELBOW

$

$

Not available

31

Toro 973370

0-Ring
(Superseded to 237-42)

$3.49

$

In Stock, Qty 20+

0

32

Toro 110942

CAP VENTED B

$

$

Not available

33

Toro 900200

BOLT 1/4-20 X 1 3/4

$

$

Not available

34

Toro 5466

SPEED NUT

$

$

Not available

35

Toro 2833

SPACER

$

$

Not available

36

Toro 920007

USE 920007P WASHER
(Superseded to 3256-22)

$0.99

$

In Stock, Qty 20+

0

37

Toro 915111

Nut
(Superseded to 3217-5)

$0.99

$

In Stock, Qty 8

0

38

Toro 908041

Bolt
(Superseded to 323-13)

$1.99

$

In Stock, Qty 20+

0

39

Toro 810395R1

Repair Manual

$

$

Currently unavailable

40

Toro 110939

PLUG-WITH O-RING

$

$

Not available

41

Toro 973620

O-ring
(Superseded to 110939)

$

$

Not available

42

Toro 108898

Clamp
(Superseded to 950154)

$

$

Not available

43

Toro 110954

Reservoir Tank Only
(Superseded to 110952)

$

$

Not available

44

Toro 110941

FITTING

$

$

Not available

45

Toro 104047

BUSHING
(Superseded to 46-6560)

$5.99

$

In Stock, Qty 20+

0
