19A40024 (19A40024100) - Cub Cadet 42" 3X Snow Thrower Attachment (2015 & Before) att2 Spindle Assembly Parts Diagram

42" 3X Snow Thrower Attachment

Spindle Assembly Parts Diagram

  • Title

1

Cub Cadet 918-07070

Spindle Housing

$72.99

$

Usually ships in 3-6 days

0

1

Cub Cadet 684-05082-0637

Spindle Hanger Bracket
(Superseded to 684-05082A-0637)

$420.99

$

Usually ships in 3-6 days

0

1

Cub Cadet 710-1260A

Hex Washer Screw, 5/16-18 x .750

$3.99

$

In Stock, Qty 20+

0

2

Cub Cadet 684-05077-0637

Bracket Assembly, Hanger, Right
(Superseded to 684-05077)

$73.99

$

In Stock, only 1 left!

0

3

Cub Cadet 684-05078-0637

Bracket Assembly, Hanger, Left
(Superseded to 684-05078)

$77.99

$

In Stock, only 2 left!

0

4

Cub Cadet 710-0347

Hex Screw, 3/8-16, 1.75, Gr5, Std

$5.49

$

In Stock, Qty 20+

0

5

Cub Cadet 710-3001

Hex Screw, 3/8-16, .880, Gr5, Std

$7.49

$

In Stock, Qty 9

0

6

Cub Cadet 710-3005

Hex Screw, 3/8-16, 1.25, Gr5, Std

$3.99

$

In Stock, Qty 11

0

7

Cub Cadet 710-3144

Hex Screw, 3/8-16, 2.00, Gr5, Std

$4.49

$

In Stock, Qty 8

0

8

Cub Cadet 711-0309A

Pin, Clevis, .62 Dia.

$12.99

$

In Stock, Qty 6

0

9

Cub Cadet 711-06303

Shaft, .375Od x 12.3450 Lg

$24.99

$

Usually ships in 3-6 days

0

10

Cub Cadet 911-1000

Keeper, Belt, .25 Dia x 3.0

$10.99

$

In Stock, only 2 left!

0

11

Cub Cadet 712-04063

Nut, Flange Lock, 5/16-18, Grf, Nylon

$3.99

$

In Stock, Qty 20+

0

12

Cub Cadet 712-04064

Nut, Flange Lock, 1/4-20, Grf, Nylon

$3.99

$

In Stock, Qty 20+

0

13

Cub Cadet 712-04065

Nut, Flange Lock, 3/8-16, Grf, Nylon

$3.99

$

In Stock, Qty 20+

0

14

Cub Cadet 714-0117

Pin, Cotter, Int, .148 x 3.00

$4.49

$

In Stock, Qty 6

0

15

Cub Cadet 714-04043

Pin, Cotter, Bow-Tie 91

$4.99

$

In Stock, Qty 20+

0

16

Cub Cadet 732-0470A

Spring, Extension, .53 Dia x 4.75 Lg
(Superseded to 932-0470A)

$9.99

$

In Stock, Qty 7

0

17

Cub Cadet 732-04927

Spring, Extension, 1.25 OD x 8.5 Lg.

$22.99

$

In Stock, Qty 20+

0

18

Cub Cadet 732-05218

Spring, Extension, 6.45 Lg

$8.49

$

Usually ships in 3-6 days

0

19

Cub Cadet 736-0262

Washer, Flat, .385 x .870 x .092

$3.99

$

Usually ships in 3-6 days

0

20

Cub Cadet 736-0518

Washer, Thrust, .445 x 1.92 x .060

$10.99

$

Usually ships in 3-6 days

0

21

Cub Cadet 712-04150

Nut, Flange Lock, 1/2-13, Grf, Nylon

$4.49

$

Usually ships in 3-6 days

0

22

Cub Cadet 738-04162C

Spacer, Shoulder, .8840 x .190

$13.99

$

In Stock, Qty 20+

0

23

Cub Cadet 738-0754

Screw, Shoulder, .437 Dia. x .54

$4.49

$

In Stock, only 2 left!

0

24

Cub Cadet 738-0966A

Bolt, Shoulder, .50 x .925, 3/8-16

$4.99

$

In Stock, Qty 19

0

25

Cub Cadet 747-06399

Rod, Keeper, Engine Pulley

$94.99

$

Usually ships in 3-6 days

0

26

Cub Cadet 747-06429

Rod, Lock, .500

$35.99

$

In Stock, only 2 left!

0

27

Cub Cadet 748-05037

Spacer, Shoulder, Idler Pivot
(Superseded to 748-05037B)

$5.49

$

In Stock, Qty 10

0

28

Cub Cadet 954-05061

Belt, V-type, Bsec, 68.2
(Superseded to 954-05061A)

$78.99

$

Usually ships in 3-6 days

0

29

Cub Cadet 756-05034

Pulley, Idler, 4.50" Dia
(Superseded to 756-05034A)

$45.99

$

In Stock, Qty 20+

0

30

Cub Cadet 956-3045A

Pulley, Idler, 5.06 Dia

$57.99

$

In Stock, Qty 6

0

31

Cub Cadet 783-08389

Cap, Pulley, Hd

$5.99

$

In Stock, Qty 20+

0

32

Cub Cadet 790-00617-0637

Bracket, Link

$106.99

$

Usually ships in 3-6 days

0

33

Cub Cadet 790-00629-0637

Bracket, Idler, Pivot

$58.99

$

Usually ships in 3-6 days

0

34

Cub Cadet 790-00630-0637

Bracket

$34.99

$

Usually ships in 3-6 days

0

35

Cub Cadet 790-00634A

Bracket, Idler, Pivot

Variations

Cub Cadet 790-00634A-0637

BRACKET-IDLER PIVOT - POWDER BLACK (0637)

$51.99

$

Usually ships in 3-6 days

0

$41.99

$

Usually ships in 3-6 days

0

36

Cub Cadet 710-06133

Screw, M6-1 x .625"

$3.99

$

In Stock, Qty 5

0

37

Cub Cadet 710-0505

Hex Screw, 7/16-14, 1.00, Gr5, Std

$6.99

$

Usually ships in 3-6 days

0

38

Cub Cadet 712-04337

Nut, Flange Lock, 7/16-14

$3.99

$

Usually ships in 3-6 days

0

39

Cub Cadet 710-3131

Hex Screw, 1/2-13, 1.00, Gr5, Std

$5.49

$

In Stock, only 1 left!

0
