1691965 - Simplicity Lever Steer Rear-Engine Riding Mower, 16hp Steering Linkage Group Parts Diagram

Lever Steer Rear-Engine Riding Mower, 16hp

Steering Linkage Group Parts Diagram

  • Title

1

Simplicity 1960027SM

WASHER, Plain
(Superseded to 703128)

$3.49

$

In Stock, Qty 20+

0

2

Simplicity 1921971SM

CAPSCREW, Hex, 5/16-18 x 1-1/4
(Superseded to 704289)

$4.99

$

In Stock, Qty 13

0

3

Simplicity 2118132SM

BEARING, Flanged

$

$

Not available

4

Simplicity 1921978SM

CAPSCREW, Hex Head 5/16-18 x 2 G5
(Superseded to 703867)

$4.99

$

In Stock, only 4 left!

0

5

Simplicity 1923362SM

LOCKNUT, Unitorque, 5/16-18
(Superseded to 703164)

$3.49

$

In Stock, Qty 19

0

6

Simplicity 1710465

SPRING, Friction

$

$

Not available

7

Simplicity 1710463

BAR, Friction

$

$

Not available

8

Simplicity 1710464

PAD, Friction

$

$

Not available

9

Simplicity 1916950SM

NUT, Hex, 3/8-16
(Superseded to 703577)

$4.49

$

In Stock, Qty 20+

0

10

Simplicity 1711572

LINK ASSY., Control

$

$

Not available

11

Simplicity 1960394SM

COTTER PIN

$3.49

$

Usually ships in 2-12 days

0

12

Simplicity 1710437SM

SPACER

$18.99

$

Usually ships in 2-12 days

0

13

Simplicity 1711586

BRACKET ASSY., Speed Adjust, R.H.

$

$

Not available

14

Simplicity 1918451SM

COTTER PIN

$3.99

$

Usually ships in 2-12 days

0

15

Simplicity 1711587

BRACKET ASSY., Speed Adjust, L.H.

$

$

Not available

16

Simplicity 1712507

CONTROL ASSY., L.H.

$

$

Not available

17

Simplicity 1711576

JOINT ASSY., L.H.

$

$

Not available

18

Simplicity 1712506

CONTROL ASSY., R.H.

$

$

Not available

19

Simplicity 1712183

SPRING, Lower

$

$

Not available

20

Simplicity 2860397SM

KEY, Woodruff, 1/8-1/2

$4.49

$

Usually ships in 2-12 days

0

21

Simplicity 1710428

ARM ASSY., Control

$

$

Not available

22

Simplicity 1923141SM

CAPSCREW, Hex, 5/16-18 x 2-3/4
(Superseded to 703869)

$6.49

$

Usually ships in 2-12 days

0

23

Simplicity 1710440

SPRING, Handle

$

$

Not available

24

Simplicity 1711574

JOINT ASSY., R.H.

$

$

Not available

25

Simplicity 1710136SM

SPRING, Upper

$

$

Not available

26

Simplicity 1712204

TURNBUCKLE

$

$

Not available

27

Simplicity 1916622SM

NUT, Hex, 1/4-20
(Superseded to 703127)

$3.49

$

In Stock, Qty 20+

0

28

Simplicity 1712184

STOP ASSY., Forward Travel

$

$

Not available

29

Simplicity 1919326SM

WASHER, Plain

$4.49

$

In Stock, Qty 8

0

30

Simplicity 1917356SM

LOCKWASHER, Spring, 5/16
(Superseded to 703116)

$3.49

$

In Stock, Qty 20+

0

31

Simplicity 1917372SM

NUT, Hex, 5/16-18
(Superseded to 7091511SM)

$3.49

$

In Stock, Qty 20+

0

32

Simplicity 1921333SM

CAPSCREW, Hex, 5/16-18 x 1
(Superseded to 703585)

$4.99

$

In Stock, only 1 left!

0

33

Simplicity 1916965SM

LOCKWASHER, Spring, 3/8
(Superseded to 703454)

$3.49

$

In Stock, Qty 17

0

34

Simplicity 1669597SM

SET COLLAR

$4.99

$

Usually ships in 2-12 days

0

35

Simplicity 1928804SM

SET SCREW, Sq. Hd., 1/4-20 x 3/8

$4.49

$

Usually ships in 2-12 days

0
