1690557 - Simplicity 36" & 42" Snow Thrower Hitch 36" & 42" Hitch and Winterizing Kit Parts Diagram

36" & 42" Snow Thrower Hitch

36" & 42" Hitch and Winterizing Kit Parts Diagram

  • Title

1

Simplicity 177048

SHIELD, Carburetor

$

$

Not available

2

Simplicity 1665789

DEFLECTOR ASSY

$

$

Not available

3

Simplicity 2106788

CLIP, Spring

$

$

Not available

4

Simplicity 1923701SM

CAPSCREW, Hex Hd, 3/8-16 x 2
(Superseded to 703589)

$4.49

$

Usually ships in 2-12 days

0

5

Simplicity 1924940SM

WASHER, Plain, 3/8
(Superseded to 703878)

$3.99

$

In Stock, Qty 20+

0

6

Simplicity 2171247SM

PULLY, Idler

$51.99

$

In Stock, Qty 20+

0

7

Simplicity 2162115SM

STOP, Belt
(Superseded to 2162115ASM)

$12.99

$

In Stock, only 1 left!

0

8

Simplicity 1916965SM

LOCKWASHER, 3/8
(Superseded to 703454)

$3.49

$

In Stock, Qty 18

0

9

Simplicity 1916950SM

NUT, Hex, Full, 3/8-16
(Superseded to 703577)

$4.49

$

In Stock, Qty 20+

0

10

Simplicity 1666785ASM

HITCH ASSY

$

$

Not available

11

Simplicity 2156306SM

PIN

$7.49

$

In Stock, Qty 14

0

12

Simplicity 2177565ASM

CLIP, Frame

$13.99

$

In Stock, only 2 left!

0

13

Simplicity 1930650SM

LOCKNUT, Hex, Flange, 7/16-14

$5.49

$

In Stock, only 4 left!

0

14

Simplicity 1917372SM

NUT, Hex, Full, 5/16-18
(Superseded to 7091511SM)

$3.49

$

In Stock, Qty 20+

0

15

Simplicity 1917356SM

LOCKWASHER, 5/16
(Superseded to 703116)

$3.49

$

In Stock, Qty 20+

0

16

Simplicity 1920676SM

CAPSCREW, Hex Hd, 7/16-14 x 1

$5.49

$

In Stock, Qty 16

0

17

Simplicity 1920415SM

CAPSCREW, Hex Hd, 3/8-16 x 1-1/4
(Superseded to 703871)

$4.99

$

Usually ships in 2-12 days

0

18

Simplicity 2174242SM

SPACER

$14.99

$

Usually ships in 2-12 days

0

19

Simplicity 2176012SM

CLIP, Spring
(Superseded to 703852)

$4.49

$

In Stock, Qty 20+

0

20

Simplicity 1667698SM

STOP, Belt

$16.99

$

Usually ships in 2-12 days

0

21

Simplicity 1919326SM

WASHER, Plain, 5/16

$4.49

$

In Stock, Qty 9

0

22

Simplicity 1921332SM

CAPSCREW, Hex Hd, 5/16-18 x 3/4
(Superseded to 704287)

$3.99

$

In Stock, Qty 9

0

23

Simplicity 1729258SM

COLLAR, Set
(Superseded to 5010477YP)

$

$

Not available

24

Simplicity 1928721SM

SETSCREW, 5/16-18 x 1/2

$4.99

$

In Stock, Qty 5

0

25

Simplicity 2171679SM

GUIDE ASSY, Rod

$76.99

$

Usually ships in 2-12 days

0

26

Simplicity 1666285SM

ROD, Lift

$104.99

$

Usually ships in 2-12 days

0

27

Simplicity 2171011SM

SPRING

$75.99

$

In Stock, only 1 left!

0

28

Simplicity 1921960SM

CAPSCREW, Hex Hd, 1/4-20 x 1

Note: Winterizing Kit, Part No. 1690565 Includes Ref. Nos. 1, 2, 28, 29, 30 & 31; for use with Briggs & Stratton 16 HP single cylinder only.

$3.49

$

In Stock, only 1 left!

0

29

Simplicity 2172656SM

SPACER

Note: Winterizing Kit, Part No. 1690565 Includes Ref. Nos. 1, 2, 28, 29, 30 & 31; for use with Briggs & Stratton 16 HP single cylinder only.

$21.99

$

Usually ships in 2-12 days

0

30

Simplicity 1916964SM

LOCKWASHER, 1/4
(Superseded to 704133)

Note: Winterizing Kit, Part No. 1690565 Includes Ref. Nos. 1, 2, 28, 29, 30 & 31; for use with Briggs & Stratton 16 HP single cylinder only.

$3.99

$

In Stock, Qty 11

0

31

Simplicity 1916622SM

NUT, Hex, Full, 1/4-20
(Superseded to 703127)

Note: Winterizing Kit, Part No. 1690565 Includes Ref. Nos. 1, 2, 28, 29, 30 & 31; for use with Briggs & Stratton 16 HP single cylinder only.

$3.49

$

In Stock, Qty 20+

0

32

Simplicity 1666798SM

V-BELT, Drive

$75.99

$

In Stock, Qty 7

0

33

Simplicity 1922130SM

CAPSCREW, Hex Hd, 3/8-16 x 2-1/4
(Superseded to 703872)

$4.99

$

In Stock, Qty 20+

0

34

Simplicity 1676267SM

REFLECTOR, Rear

$19.99

$

Usually ships in 2-12 days

0
