161-JU - MTD 123cc Engine 161-JU General Assembly Parts Diagram

123cc Engine

161-JU General Assembly Parts Diagram

  • Title

1

MTD 710-04968

BOLT M6 x 16

$6.99

$

In Stock, only 3 left!

0

2

MTD 951-11054B

VALVE COVER

$15.99

$

Usually ships in 3-6 days

0

3

MTD 951-14090

BREATHER HOSE

$7.99

$

Usually ships in 3-6 days

0

4

MTD 751P11565B

VALVE COVER GASKET

$10.99

$

Usually ships in 3-6 days

0

5

MTD 951-11892

ROCKER ARM ASSEMBLY

$40.99

$

Usually ships in 3-6 days

0

6

MTD 951-15139

ROCKER ARM BASE

$6.99

$

Usually ships in 3-6 days

0

7

MTD 951-12002

EXHAUST VALVE ADJUSTER
(Superseded to 751P12002A)

$2.99

$

Usually ships in 3-6 days

0

8

MTD 951-12000

INTAKE VALVE SPRING RETAINER

$4.49

$

In Stock, only 1 left!

0

9

MTD 951-12003

EXHAUST VALVE SPRING RETAINER

$4.49

$

In Stock, only 1 left!

0

10

MTD 951-12004

VALVE SPRING
(Superseded to 751P12004A)

$1.99

$

In Stock, Qty 5

0

11

MTD 951-11894

INTAKE VALVE SEAL

$10.99

$

Usually ships in 3-6 days

0

12

MTD 951-14086

INTAKE VALVE

$9.49

$

Usually ships in 3-6 days

0

13

MTD 951-14087

EXHAUST VALVE

$11.99

$

Usually ships in 3-6 days

0

14

MTD 710-04922

BOLT M8 x 50

$4.49

$

Usually ships in 3-6 days

0

15

MTD 710-04911

STUD M8 x 36

$4.49

$

Usually ships in 3-6 days

0

16

MTD 951-10292

SPARK PLUG
(Superseded to 951-10292A)

$6.99

$

In Stock, Qty 20+

0

17

MTD 951-10959

MUFFLER GASKET

$4.99

$

Usually ships in 3-6 days

0

18

MTD 951-10901

MUFFLER ASSEMBLY

$70.99

$

Usually ships in 3-6 days

0

19

MTD 710-06119

BOLT M5-.8 x 8 CL10.9

$5.99

$

Usually ships in 3-6 days

0

22

MTD 712-04214

NUT

$4.49

$

In Stock, Qty 5

0

23

MTD 951-14088

CYLINDER HEAD

$81.99

$

Usually ships in 3-6 days

0

24

MTD 710-04909

STUD M6-1 x 113

$4.49

$

Usually ships in 3-6 days

0

25

MTD 951-12610

CARBURETOR INSULATOR GASKET
(Superseded to 951-12610B)

$4.99

$

In Stock, only 1 left!

0

26

MTD 951-12611

CARBURETOR INSULATOR

$5.49

$

In Stock, only 1 left!

0

27

MTD 751P12005A

CARBURETOR GASKET

$5.99

$

In Stock, Qty 20+

0

28

MTD 951-14093

CARBURATOR

$109.99

$

Usually ships in 3-6 days

0

29

MTD 951-11571

CARBURETOR GASKET PLATE

$5.99

$

In Stock, Qty 8

0

30

MTD 951-14796

HEATER BOX HOUSING

$17.99

$

Usually ships in 3-6 days

0

31

MTD 712-05015

HEX NUT

$6.99

$

In Stock, Qty 6

0

32

MTD 951-14795

FUEL HOSE 3.2X6.5X530

$9.49

$

Usually ships in 3-6 days

0

33

MTD 951-10639A

PRIMER

$15.99

$

In Stock, Qty 17

0

34

MTD 712-05015

HEX NUT

$6.99

$

In Stock, Qty 6

0

35

MTD 710-04914

BOLT M6-1 x 10 GR8.8

$4.49

$

In Stock, only 3 left!

0

36

MTD 951-14781

SHROUD

$11.99

$

Usually ships in 3-6 days

0

37

MTD 710-05275

BOLT M4.2 x 16

$3.99

$

In Stock, Qty 13

0

38

MTD 951-10961

INTAKE HEATER BOX

$16.99

$

In Stock, only 2 left!

0

39

MTD 951-12609

CYLINDER HEAD GASKET

$11.99

$

Usually ships in 3-6 days

0

40

MTD 715-04108

DOWEL PIN

$4.49

$

In Stock, only 1 left!

0

41

MTD 951-11174

SINGLE PUSH ROD

$6.99

$

Usually ships in 3-6 days

0

42

MTD 951-11899

TAPPET

$8.49

$

In Stock, only 4 left!

0

43

MTD 951-12615

PISTON RING KIT

$18.99

$

Usually ships in 3-6 days

0

44

MTD 951-11603

SNAP RING-PISTON PIN

$4.49

$

Usually ships in 3-6 days

0

45

MTD 951-11828

PISTON

$34.99

$

Usually ships in 3-6 days

0

46

MTD 951-11604

PISTON PIN

$7.99

$

Usually ships in 3-6 days

0

47

MTD 951-12616

CONNECTING ROD ASSEMBLY

$77.99

$

Usually ships in 3-6 days

0

48

MTD 751P11368A

OIL SEAL

$3.49

$

In Stock, Qty 13

0

49

MTD 710-04943

BOLT-M6-1 x 28 GR8.8

$4.49

$

In Stock, only 2 left!

0

50

MTD 951-12619

DIPSTICK ASSEMBLY

$11.99

$

Usually ships in 3-6 days

0

52

MTD 951-11577

O-RING 15.8 x 2.5

$4.49

$

Usually ships in 3-6 days

0

53

MTD 951-14081

CRANKCASE COVER

$81.99

$

Usually ships in 3-6 days

0

54

MTD 951-12618

CRANKCASE COVER GASKET

$13.99

$

Usually ships in 3-6 days

0

55

MTD 715-04096

DOWEL PIN
(Superseded to 715-04096A)

$4.49

$

Usually ships in 3-6 days

0

56

MTD 715-04096

DOWEL PIN
(Superseded to 715-04096A)

$4.49

$

Usually ships in 3-6 days

0

57

MTD 951-11369

BEARING

$34.99

$

Usually ships in 3-6 days

0

58

MTD 951-12046

CAMSHAFT ASSEMBLY

$65.99

$

Usually ships in 3-6 days

0

59

MTD 951-14080

CRANKSHAFT

$142.99

$

Usually ships in 3-6 days

0

60

MTD 951-10307

FLYWHEEL KEY
(Superseded to 751P10307A)

$2.49

$

Usually ships in 3-6 days

0

61

MTD 951-12617

GOVERNOR GEAR/SHAFT ASSEMBLY

$11.99

$

Usually ships in 3-6 days

0

62

MTD 951-14053

GOVERNOR SHAFT

$15.99

$

Usually ships in 3-6 days

0

63

MTD 736-04461

O-RING

$3.99

$

Usually ships in 3-6 days

0

64

MTD 951-11902

GOVERNOR SEAL
(Superseded to 951-11902A)

$3.99

$

In Stock, only 2 left!

0

65

MTD 714-04078

COTTER PIN

$4.49

$

In Stock, only 1 left!

0

66

MTD 951-14089

GOVERNOR LEVER

$7.99

$

Usually ships in 3-6 days

0

67

MTD 951-10953

GOVERNOR-RETURN SPRING

$5.99

$

Usually ships in 3-6 days

0

68

MTD 951-10954

THROTTLE RETURN SPRING

$6.49

$

In Stock, only 2 left!

0

69

MTD 951-11152

GOVERNOR ROD

$6.99

$

In Stock, Qty 5

0

70

MTD 951-11103

COVER SHIELD

$4.49

$

Usually ships in 3-6 days

0

71

MTD 710-04921

BOLT M8-1.25 x 14 GR8.8

$5.49

$

Usually ships in 3-6 days

0

72

MTD 951-11104

GOVERNOR SPRING BRACKET

$3.99

$

Usually ships in 3-6 days

0

73

MTD 710-04915

BOLT M6-1 x 12 GR8.8

$4.49

$

In Stock, only 3 left!

0

74

MTD 751-14082

CRANKCASE
(Superseded to 751P14082)

$114.99

$

Usually ships in 3-6 days

0

75

MTD 951-12514A

OIL PLUG 1/8 NPT

$6.49

$

Usually ships in 3-6 days

0

76

MTD 951-12622

OIL SEAL

$14.99

$

Usually ships in 3-6 days

0

77

MTD 951-11102

OIL ALERT SIDE PLATE

$3.99

$

Usually ships in 3-6 days

0

78

MTD 951-10958A

IGNITION COIL

$97.99

$

Usually ships in 3-6 days

0

79

MTD 710-04919

BOLT M6-1 x 25 GR8.8

$4.49

$

Usually ships in 3-6 days

0

80

MTD 951-10908

FLYWHEEL

$112.99

$

Usually ships in 3-6 days

0

81

MTD 951-10910

COOLING FAN

$50.99

$

Usually ships in 3-6 days

0

82

MTD 951-10911

STARTER CUP

$17.99

$

Usually ships in 3-6 days

0

83

MTD 712-04287

FLYWHEEL NUT

$6.99

$

In Stock, only 1 left!

0

84

MTD 651-05486

RECOIL STARTER HOUSING
(Superseded to 651P05486A)

$58.99

$

Usually ships in 3-6 days

0

85

MTD 751-15608

BLOWER HOUSING
(Superseded to 751P15608A)

$25.99

$

Usually ships in 3-6 days

0

86

MTD 751-15609

RECOIL STARTER

$

$

Currently unavailable

87

MTD 736-04455

RECOIL FLAT WASHER
(Superseded to 736-04455B)

$6.99

$

Usually ships in 3-6 days

0

88

MTD 710-06354

BOLT M6 x 10

$6.99

$

Usually ships in 3-6 days

0

a

MTD 710-05468

CHOKE CONTROL LEVER SCREW

$3.99

$

Usually ships in 3-6 days

0

b

Washer, 3

$

$

Not available

c

Washer, 3

$

$

Not available

d

MTD 951-12811

CHOKE CONTROL LEVER

$11.99

$

In Stock, only 1 left!

0

e

Choke Shaft

$

$

Not available

f

Choke Plate

$

$

Not available

g

Throttle Shaft

$

$

Not available

h

Throttle Plate

$

$

Not available

i

Screw, M3×6

$

$

Not available

j

Gasket

$

$

Not available

k

Idle Jet

$

$

Not available

l

Idle Adjusting Screw

$

$

Not available

m

MTD 951-12019A

PRIMER HOSE

$7.49

$

In Stock, only 2 left!

0

n

Carburetor Body

$

$

Not available

o

Fuel Nipple

$

$

Not available

p

MTD 711-06043

HINGE FLOAT PIN

$0.99

$

Usually ships in 3-6 days

0

q

Nozzle Tube

$

$

Not available

r

MTD 793P00165

NEEDLE VALVE
(Superseded to 793P00165A)

$4.99

$

In Stock, Qty 11

0

s

Main Jet

$

$

Not available

t

MTD 732P05251

NEEDLE VALVE SPRING
(Superseded to 732P05251A)

$1.99

$

Usually ships in 3-6 days

0

u

Float

$

$

Not available

v

MTD 951-11589

FUEL BOWL O-RING
(Superseded to 951-11589A)

$6.99

$

In Stock, Qty 20+

0

w

Float Bowl

$

$

Not available

x

MTD 951-11348

FUEL BOWL GASKET
(Superseded to 951-11348A)

$5.99

$

Usually ships in 3-6 days

0

y

MTD 710-04945

BOLT M8-1 x 10

$4.49

$

In Stock, only 4 left!

0

Z

MTD 951-11349

FUEL DRAIN PLUG GASKET
(Superseded to 951-11349A)

$4.49

$

In Stock, Qty 11

0

aa

MTD 710-04938

FUEL DRAIN PLUG

$4.49

$

In Stock, only 1 left!

0

MTD 752Z161-JU
