1576-0 - Generac 3,600 Watt Portable Generator Main Unit Parts Diagram

3,600 Watt Portable Generator

Main Unit Parts Diagram

  • Title

1

Briggs & Stratton A188300

CRADLE

$

$

Currently unavailable

2

Briggs & Stratton 85651

MOUNT, Vibration
(Superseded to 85651GS)

$24.99

$

Usually ships in 2-12 days

0

3

Briggs & Stratton ~NSP

ENGINE

$

$

Currently unavailable

4

Briggs & Stratton 66365

HOUSING, Engine Adapter
(Superseded to 66365GS)

$69.99

$

Usually ships in 2-12 days

0

5

Briggs & Stratton 86307

HHMS, 5/16-24 x 3/4"
(Superseded to 86307GS)

$2.99

$

In Stock, only 3 left!

0

6

Briggs & Stratton 188075

ASSEMBLY, Rotor
(Superseded to 188075GS)

$223.99

$

Usually ships in 2-12 days

0

7

Briggs & Stratton 65791

BEARING
(Superseded to 65791GS)

$34.99

$

Usually ships in 2-12 days

0

8

Briggs & Stratton 96796

WASHER, M8 Flat
(Superseded to 96796GS)

$3.49

$

Usually ships in 2-12 days

0

9

Briggs & Stratton 24823

HHCS, 5/16-24 x 7-7/8"
(Superseded to 24823GS)

$18.99

$

Usually ships in 2-12 days

0

10

Briggs & Stratton 91838J

ASSEMBLY, Stator
(Superseded to 91838JGS)

$

$

Not available

11

Briggs & Stratton 66825B

CARRIER, Rear Bearing

$

$

Currently unavailable

12

Briggs & Stratton 67022

GROMMET, Rubber
(Superseded to 67022GS)

$3.49

$

Usually ships in 2-12 days

0

13

Briggs & Stratton 86308

BOLT, M6 - 1.0 x 115
(Superseded to 86308GS)

$3.99

$

Usually ships in 2-12 days

0

14

Briggs & Stratton 66849A

TAPTITE, M5 0.8 x 20
(Superseded to 66849AGS)

$4.49

$

Usually ships in 2-12 days

0

15

Briggs & Stratton 65795

RECTIFIER, Battery Charge
(Superseded to 65795GS)

$

$

Not available

16

Briggs & Stratton 95003A

ASSEMBLY, Control Panel
(Superseded to 95003AGS)

$114.99

$

Usually ships in 2-12 days

0

17

Briggs & Stratton 188552

DECAL, Control Panel

$

$

Currently unavailable

18

Briggs & Stratton 74908

TAPTITE, M5-0.8 x 10
(Superseded to 74908GS)

$2.99

$

Usually ships in 2-12 days

0

19

Briggs & Stratton 84409

SLEEVING, Flexo, HW 1/2" X .83ft.

$

$

Currently unavailable

20

Briggs & Stratton 91825

ASSEMBLY, Brush Holder

$

$

Not available

21

Briggs & Stratton 66849

TAPTITE, M5 0.8 x 16
(Superseded to 66849GS)

$4.99

$

Usually ships in 2-12 days

0

22

Briggs & Stratton 67989

NUT, M8 Flanged Serrated
(Superseded to 67989GS)

$3.49

$

In Stock, Qty 5

0

23

Briggs & Stratton B4986

DECAL, Ground
(Superseded to B4986GS)

$2.99

$

In Stock, only 1 left!

0

24

Briggs & Stratton 77816

DECAL, Caution Hot Muffler
(Superseded to 77816GS)

$4.99

$

Usually ships in 2-12 days

0

25

Briggs & Stratton 85652

MOUNT, Vibration
(Superseded to 194153GS)

$11.99

$

In Stock, Qty 5

0

26

Briggs & Stratton 84242

GROMMET, Rubber
(Superseded to 84242GS)

$4.99

$

Usually ships in 2-12 days

0

27

Briggs & Stratton 81917

PIN, Roll M4 x 10
(Superseded to 81917GS)

$3.49

$

Usually ships in 2-12 days

0

28

Briggs & Stratton 36781

SHCS, 1/4 - 20 x 3/4"

$

$

Currently unavailable

29

Briggs & Stratton 83083

SCREEN, Spark Arrest
(Superseded to 83083GS)

$9.49

$

In Stock, only 2 left!

0

30

Briggs & Stratton 188301

MUFFLER
(Superseded to 188301GS)

$152.99

$

Usually ships in 2-12 days

0

31

Briggs & Stratton 66476

HHMS, LW M6 1.00 x 12
(Superseded to 66476GS)

$3.49

$

Usually ships in 2-12 days

0

32

Briggs & Stratton 83208

BRACKET, Muffler
(Superseded to 83208GS)

$21.99

$

Usually ships in 2-12 days

0

33

Briggs & Stratton 84346

PPHMS, M8 x 35
(Superseded to 195398GS)

$2.99

$

In Stock, only 1 left!

0

34

Briggs & Stratton 73054

DECAL, Fuel Shut Off

$

$

Not available

35

Briggs & Stratton 188553

DECAL, Heat Shield

$

$

Currently unavailable

36

Briggs & Stratton 85000

CLIP, Insulation
(Superseded to 85000GS)

$2.99

$

Usually ships in 2-12 days

0

37

Briggs & Stratton B84042

SHIELD, Heat
(Superseded to B84042GS)

$38.99

$

Usually ships in 2-12 days

0

38

Briggs & Stratton 84687

INSULATION, #2-1/4" Thick
(Superseded to 84687GS)

$22.99

$

Usually ships in 2-12 days

0

39

Briggs & Stratton 88325

TANK, Fuel
(Superseded to 195617GS)

$

$

Not available

40

Briggs & Stratton 85134

GAUGE, Fuel
(Superseded to B4363GS)

$41.99

$

In Stock, Qty 20+

0

41

Briggs & Stratton 93826

DECAL, Operating Instructions
(Superseded to 93826GS)

$14.99

$

Usually ships in 2-12 days

0

42

Briggs & Stratton 92982

DECAL, Danger
(Superseded to 194799GS)

$11.99

$

Usually ships in 2-12 days

0

43

Briggs & Stratton 78831B

HHMS, M6 1.0 x 60
(Superseded to 78831BGS)

$

$

Not available

44

Briggs & Stratton 83465

GROMMET, Tank
(Superseded to 83465GS)

$3.99

$

In Stock, only 4 left!

0

45

Briggs & Stratton 77395

NUT, M6 Flange Lock
(Superseded to 77395GS)

$3.99

$

Usually ships in 2-12 days

0

46

Briggs & Stratton 80270

VALVE, Tank
(Superseded to 192980GS)

$17.99

$

In Stock, Qty 20+

0

47

Briggs & Stratton 78299

BUSHING, Plastic Tank
(Superseded to 192980GS)

$17.99

$

In Stock, Qty 20+

0

48

Briggs & Stratton 26850

WASHER, M6 Shakeproof

$

$

Not available

49

14353621

WIRE, Ground

$

$

Not available

50

Briggs & Stratton 86494

SCREW, M6 -1.0 x 16 Wing
(Superseded to 86494GS)

$2.99

$

Usually ships in 2-12 days

0

51

Briggs & Stratton 23762

WASHER, Shakeproof #10
(Superseded to 23762GS)

$2.99

$

Usually ships in 2-12 days

0

52

Briggs & Stratton B2153

HHCS, 12 - 14 x 7/8" Self Driller
(Superseded to B2153GS)

$4.49

$

Usually ships in 2-12 days

0

53

Briggs & Stratton 188629

GASKET, Exhaust

$

$

Currently unavailable

54

Briggs & Stratton 188637

MANUAL, Engine
(Superseded to 188637GS)

$14.99

$

Usually ships in 2-12 days

0

55

Briggs & Stratton 188373

MANUAL, Owners

$

$

Not available

56

Briggs & Stratton 43483

PLUG, 250V, 20 Amp
(Superseded to 100522GS)

$34.99

$

Usually ships in 2-12 days

0
