13B-325-401 - Yard-Man Lawn Tractor (1999) Deck Accessory - Three-In-One Parts Diagram

Lawn Tractor

Deck Accessory - Three-In-One Parts Diagram

1

MTD 631-0060

Flow indicator
(Superseded to 931-0060)

$

$

Not available

2

MTD 710-0286

Truss Mach. Scr. 1/4-20 x .50

$4.49

$

Usually ships in 3-6 days

0

3

MTD 710-0564

Hex Bolt 1/4-20 x 2.75"

$6.99

$

In Stock, only 3 left!

0

4

MTD 710-0642

Hex washer TT Scr. 1/4-20 x .75

$4.49

$

In Stock, Qty 20+

0

5

MTD 710-0825

Hex Bolt 1/4-20 x 3.75"

$5.49

$

In Stock, only 3 left!

0

?6

MTD 710-0456

Torx Mach. TT Scr.#10 x .50

$

$

Not available

7

MTD 710-0924

Pan Head Mach. Scr. 1/4-20 x .75

$4.49

$

In Stock, Qty 20+

0

8

MTD 711-0415

Clevis Pin

$4.99

$

In Stock, Qty 20+

0

9

MTD 712-0271

Sems Hex Nut 1/4-20

$4.49

$

In Stock, Qty 19

0

10

MTD 712-0298

Hex Jam Nut
(Superseded to 912-0298)

$6.49

$

Usually ships in 3-6 days

0

11

MTD 712-0397

Wing Nut
(Superseded to 712-0397A)

$3.99

$

In Stock, Qty 20+

0

12

MTD 714-0115

Cotter Pin

$3.99

$

In Stock, only 2 left!

0

13

MTD 726-0271

Pushnut Fastener
(Superseded to 926-0271)

$6.49

$

In Stock, only 2 left!

0

14

MTD 731-1441

Bag Handle

$

$

Not available

15

MTD 731-1743A

Discharge Chute

$

$

Not available

16

MTD 731-1744

Side Discharge Chute

$

$

Not available

17

MTD 731-1745A

Mulch Plug

$

$

Not available

18

MTD 731-1912

Grass Bag Hinge

$

$

Not available

19

MTD 731-1952

Grass Bag

$

$

Not available

20

MTD 731-1953

Grass Bag Cover

$

$

Not available

21

MTD 732-0839

Bag Release Lever
(Superseded to 732-0839A)

$

$

Not available

22

MTD 732-0841

Torsion Spring
(Superseded to 932-0841)

$

$

Not available

?23

MTD 732-0854

Spring Clip

$

$

Not available

24

MTD 736-0173

Flat Washer .28 I.D. x .74 DE x 0.63

$4.49

$

In Stock, Qty 20+

0

25

MTD 710-0166

Pan Hd. Mach. Scr. 1/4-20 X 1.0
(Superseded to 710-0166A)

$7.49

$

In Stock, only 1 left!

0

26

MTD 736-0329

Lock Washer
(Superseded to 936-0329)

$4.49

$

In Stock, Qty 9

0

27

MTD 783-0544-0637

SCREEN-BAG - POWDER BLACK (0637)
(Superseded to 783-0544A-0637)

Variations

$

$

Not available

28

MTD 783-0575-0637

BRAKET-PIVOT - POWDER BLACK (0637)
(Superseded to 783-0575B-0637)

Variations

$

$

Not available

29

MTD 783-0645-0637

No Longer Available PLATE-CHUT - POWDER BLACK (0637)

Variations

$

$

Not available
