13AL608G731 - Huskee Lawn Tractor (2004) (Tractor Supply) PTO Manual, Battery, Frame Parts Diagram

Lawn Tractor

PTO Manual, Battery, Frame Parts Diagram

  • Title

1

MTD 17962

Switch Plate

$4.99

$

In Stock, only 3 left!

0

2

MTD 647-0064

Lever Assembly: PTO Engage

$

$

Not available

3

MTD 683-0450

Plate Assembly: PTO Engage

Variations

MTD 683-0450-0637

PLATE ASM-ENGAGE - POWDER BLACK (0637)

$

$

Not available

$

$

4

MTD 710-0224

AB Screw #10-16 x 0.5
(Superseded to 910-0224)

$3.99

$

In Stock, Qty 20+

0

5

MTD 710-0276

Carriage Screw: Special

$3.99

$

In Stock, Qty 10

0

6

MTD 710-0520

Hex Bolt 3/8-16 x 1.5

$4.49

$

In Stock, Qty 6

0

7

MTD 710-0726

AB Screw 5/16-12 0.75

$4.49

$

In Stock, Qty 20+

0

8

MTD 710-0831

Hex Bolt 3/8-16 x 5.5

$

$

Not available

9

MTD 710-3029

Hex Bolt 7/16-20 x 1.25

$4.49

$

In Stock, Qty 12

0

10

MTD 711-1044

Belt Guard Pin
(Superseded to 711-1044A)

$8.99

$

In Stock, Qty 10

0

11

MTD 712-0130

Lock Nut

$3.99

$

In Stock, Qty 11

0

12

MTD 712-0229

Push Nut

$3.99

$

In Stock, Qty 20+

0

13

MTD 712-3004A

Flange Lock Nut

$3.99

$

In Stock, Qty 20+

0

14

MTD 712-3010

Hex Nut 5/16-18

$4.49

$

In Stock, Qty 20+

0

15

MTD 714-0104

Cotter Pin

$4.49

$

In Stock, Qty 20+

0

16

MTD 714-0470

Cotter Pin

$4.49

$

In Stock, Qty 20+

0

17

MTD 726-0201

Speed Nut

$6.99

$

In Stock, only 2 left!

0

18

MTD 731-2111A

PTO Knob
(Superseded to 731-2111B)

$

$

Not available

19

MTD 732-0991A

Belt Guard

$14.99

$

Usually ships in 3-6 days

0

20

MTD 732-1013

Belt Guard
(Superseded to 732-1013A)

$10.99

$

In Stock, only 1 left!

0

21

MTD 732-1170

Extension Spring

$10.99

$

In Stock, Qty 6

0

22

MTD 736-0108

Flat Washer

$6.99

$

Usually ships in 3-6 days

0

23

MTD 736-0119

Lock Washer
(Superseded to 936-0119)

$4.99

$

In Stock, Qty 20+

0

24

MTD 736-0140

Flat Washer

$7.49

$

In Stock, Qty 7

0

25

MTD 736-0171

Lock Washer

$4.49

$

In Stock, only 4 left!

0

26

MTD 736-0242

Bell Washer

$4.49

$

In Stock, Qty 20+

0

27

MTD 736-0300

Flat Washer

$4.49

$

In Stock, Qty 20+

0

28

MTD 736-0322

Flat Washer

$9.49

$

In Stock, Qty 8

0

29

MTD 736-3039

Flat Washer

$5.49

$

In Stock, Qty 7

0

30

MTD 738-0372B

Spacer

$9.49

$

In Stock, Qty 20+

0

31

MTD 741-0708

Hex Split Flange Bearing

$4.49

$

In Stock, only 3 left!

0

32

MTD 747-1112D

Handle: Deck Engage
(Superseded to 747-1112D-0637)

Variations

MTD 747-1112D-0637

PTO Engagement Handle - POWDER BLACK (0637)

$40.99

$

Usually ships in 3-6 days

0

$40.99

$

Usually ships in 3-6 days

0

33

MTD 747-1286A

Rod: Belt Keeper

$

$

Not available

34

MTD 748-0415B

Spacer

$7.49

$

In Stock, Qty 10

0

35

MTD 750-0956

Spacer

$19.99

$

In Stock, only 2 left!

0

36

MTD 756-0627B

Idler Pulley
(Superseded to 756-0627D)

$30.99

$

In Stock, Qty 20+

0

37

MTD 756-0982B

Engine Pulley 42" deck

$72.99

$

In Stock, only 1 left!

0

37

MTD 756-04142

Engine Pulley 46/50" decks

$

$

Not available

38

MTD 756-1208

Idler Pulley

$35.99

$

In Stock, Qty 5

0

39

MTD 783-04467

Bracket: Deck Stop

Variations

MTD 783-04467-0606

BRACKET-DECK:UP STOP - MAJESTIC ORANGE (0606)

$37.99

$

Usually ships in 3-6 days

0

MTD 783-04467-0637

Deck Up-Stop Bracket - POWDER BLACK (0637)

$37.99

$

Usually ships in 3-6 days

0

MTD 783-04467-0691

Deck Up-Stop Bracket - BLACK JACK (0691)

$37.99

$

Usually ships in 3-6 days

0

MTD 783-04467-0650

BRACKET-DECK:UP STOP - RED METALLIC (0650)

$

$

Not available

MTD 783-04467-0665

BRACKET-DECK:UP STOP - YARDMAN GREEN (0665)

$

$

Not available

MTD 783-04467-0716

BRACKET-DECK:UP STOP - CUB YELLOW-99 (0716)

$

$

Not available

MTD 783-04467-4008

BRACKET-DECK:UP STOP - WINE RED (4008)

$

$

Not available

$34.99

$

Usually ships in 3-6 days

0

40

MTD 783-0744A

Bracket: Stop

Variations

MTD 783-0744A-0637

Stop Bracket - POWDER BLACK (0637)

$44.99

$

Usually ships in 3-6 days

0

MTD 783-0744A-4008

BRACKET-STOP - WINE RED (4008)

$41.99

$

Usually ships in 3-6 days

0

$41.99

$

Usually ships in 3-6 days

0

41

MTD 736-0227

Flat Washer

$6.49

$

In Stock, Qty 13

0

42

MTD 736-3010

Flat Washer

$4.99

$

In Stock, only 1 left!

0

43

MTD 683-0302

Engagement Plate Assembly

Variations

MTD 683-0302-0637

Engagement Plate Assembly - POWDER BLACK (0637)

$37.99

$

In Stock, only 1 left!

0

$37.99

$

In Stock, only 1 left!

0

44

MTD 732-0944

Extension Spring

$10.99

$

In Stock, only 1 left!

0

45

MTD 736-0275

Flat Washer

$6.99

$

Usually ships in 3-6 days

0

46

MTD 710-0347

Hex Bolt 3/8-16 x 1.75

$5.49

$

In Stock, Qty 20+

0

47

MTD 712-0429

Hex Lock Nut 5/16-18

$4.49

$

In Stock, Qty 20+

0

48

MTD 754-0497

V Belt 42'' Deck
(Superseded to 954-0497)

$45.99

$

In Stock, Qty 18

0

49

MTD 754-04064

V Belt 46'' Deck Sec B x 68.24"

$79.99

$

In Stock, only 1 left!

0

49

MTD 754-0486A

V Belt 46'' Deck Sec B x 67" models 13AS, 13CS, 13AQ
(Superseded to 954-0486A)

$58.99

$

In Stock, only 1 left!

0

MTD 783-0349

Battery Tray

Variations

MTD 783-0349-4008

TRAY-BATTERY 400 - WINE RED (4008)

$

$

Not available

MTD 783-0349-0606

TRAY-BATTERY 400 S - MAJESTIC ORANGE (0606)

$

$

Not available

MTD 783-0349-0637

Battery Tray, Powder Black - POWDER BLACK (0637)

$

$

Not available

$

$

MTD 725-1706A

Battery
(Superseded to 925-1707D)

$

$

Not available

MTD 710-0703

Carriage Screw

$4.49

$

In Stock, Qty 15

0

MTD 747-04121A

Battery Holddown rod

$6.49

$

In Stock, Qty 20+

0

MTD 712-0271

Sems Nut

$4.49

$

In Stock, Qty 20+

0

MTD 732-1165

Extension Spring
(Superseded to 732-04197)

Note: Not shown

$6.99

$

In Stock, Qty 12

0
