13A747GF062 - Yard Machines Lawn Tractor (1997) (Lowes) Muffler Chart Parts Diagram

Lawn Tractor

Muffler Chart Parts Diagram

  • Title

1

MTD 721-0208

Exhaust Gasket
(Superseded to BS-692236)

$5.49

$

In Stock, Qty 20+

0

2

MTD 710-0599

Hex Washer Hd. TT Scr. 1/4-20 x .5"

$4.49

$

In Stock, Qty 20+

0

3

MTD 683-0042A

Muffler Heat Shield - L.H.

Variations

MTD 683-0042A-0637

SHEID ASSY.HEAT - POWDER BLACK (0637)

$

$

Not available

$

$

4

MTD 710-0429

Hex B-Tap Scr. #10 x .38"
(Superseded to 910-0429)

$3.99

$

Usually ships in 3-6 days

0

5

MTD 712-0147

Speed Nut #10-24 Thd.

$6.99

$

Usually ships in 3-6 days

0

6

MTD 738-0636

Shoulder Bolt
(Superseded to 938-0636)

$

$

Not available

7

MTD 751-0465A

Muffler
(Superseded to 951-0465A)

$

$

Not available

MTD 751-0302

Muffler
(Superseded to 951-0302)

$

$

Not available

MTD 712-0250

Conduit Lock Nut

$

$

Not available

MTD 721-0208

Gasket
(Superseded to BS-692236)

$5.49

$

In Stock, Qty 20+

0

8

MTD 736-0329

Lock Washer 1/4" I.D.
(Superseded to 936-0329)

$4.49

$

In Stock, Qty 11

0

9

MTD 725-0976A

Ground Wire

$

$

Not available

10

MTD 710-0323

Truss Mach. Scr. 5/16-18 x .75"

$4.99

$

In Stock, only 2 left!

0

11

MTD 736-0175

Spring Washer 1/4" I.D.
(Superseded to 936-0175)

$3.99

$

In Stock, only 3 left!

0

12

MTD 710-0294

Hex Bolt 1/4-20 x 3/8"

$3.49

$

Usually ships in 3-6 days

0

13

MTD 16936

Muffler Heat Shield - Front

$

$

Not available
