135-397-132 - Lawnflite Lawn Tractor (1985) (Allied Hardware) Electrical Parts Diagram

Lawn Tractor

Electrical Parts Diagram

  • Title
1

MTD 725-0977

Ground Wire-11.5" Lg.

$

$

Not available

2

MTD 725-0150

Electric Wire 11.5" Lg. (Red)

$

$

Not available

3

MTD 725-0122

Electric Wire-7.25" Lg.

$

$

Not available

4

MTD 725-0514

Battery
(Superseded to 753-0607)

$170.99

$

Usually ships in 3-6 days

0

5

MTD 725-0267

Ignition Switch
(Superseded to 925-0267B)

$35.99

$

In Stock, Qty 20+

0

6

MTD 725-0819

Safety Switch
(Superseded to 925-0819A)

Note: (Blade)

$30.99

$

Usually ships in 3-6 days

0

7

MTD 725-0759

Spring Switch
(Superseded to 753-0579)

Note: (Reverse)

$

$

Not available

8

MTD 725-0771

Solenoid
(Superseded to 925-0771)

$35.99

$

In Stock, only 1 left!

0

9

MTD 725-0268

Safety Switch
(Superseded to 925-0268)

Note: (Clutch)

$39.99

$

Usually ships in 3-6 days

0

MTD 725-1026

Wire Harness Comp.

$

$

Currently unavailable
