1300 (13A-130F100) - Cub Cadet Garden Tractor Brake & Wheel Assembly Parts Diagram

Garden Tractor

Brake & Wheel Assembly Parts Diagram

  • Title

8

Cub Cadet 1100045

Hex Head Capscrew, 5/16-18 x 1
(Superseded to 710-0376)

$3.99

$

In Stock, only 4 left!

0

9

Cub Cadet 1186391

Flange Nut, 5/16-18
(Superseded to 712-04054)

$4.99

$

In Stock, Qty 20+

0

10

Cub Cadet 1100044

Hex Head Capscrew, 5/16-18 x 3/4
(Superseded to 710-3008)

$4.49

$

In Stock, Qty 20+

0

13

Cub Cadet 1733398

Top Locknut, 3/8-16
(Superseded to 912-3000)

$4.49

$

In Stock, Qty 9

0

14

Cub Cadet 1107382

Flat Washer, 5/16
(Superseded to 936-0275)

$

$

Not available

25

Cub Cadet 1113527

Retaining Ring, 3/4
(Superseded to 916-0101)

$3.99

$

In Stock, Qty 20+

0

33

Cub Cadet 1766984

Flange Lock screw, 5/16-18 x 3/4

$3.99

$

Usually ships in 3-6 days

0

40

Cub Cadet 1766241

Special Washer, 3/4 x 2-1/2

$

$

Not available

70

Cub Cadet 1107381

Flat Washer, 1/4
(Superseded to 936-3020)

$

$

Not available

81

Cub Cadet 1100048

Hex Capscrew, 3/8-16 x 2
(Superseded to 710-3144)

$4.49

$

In Stock, Qty 7

0

83

Cub Cadet 1100086

Hex Capscrew, 3/8-16 x 1-3/4
(Superseded to 710-0347)

$5.49

$

In Stock, Qty 20+

0

84

Cub Cadet 1100241

Lock Washer, 1/4 SAE
(Superseded to 936-0329)

$4.49

$

In Stock, Qty 11

0

85

Cub Cadet 1107383

Flat Washer, 3/8
(Superseded to 736-3050)

$4.49

$

In Stock, Qty 16

0

86

Cub Cadet 1100346

Cotter Pin, 3/32 x 3/4
(Superseded to 914-0507)

$4.49

$

In Stock, Qty 17

0

87

Cub Cadet 1111609

Hex Screw, 5/16-18 x 2-3/4
(Superseded to 710-0176)

$4.49

$

In Stock, only 2 left!

0

88

Cub Cadet 1186097

Carriage Bolt, 5/16-18 x 5/8
(Superseded to 710-0260A)

$4.49

$

In Stock, Qty 20+

0

90

Cub Cadet 1715538

Nyliner Bushing

$

$

Not available

91

Cub Cadet 1732499

Locknut, 5/16-18
(Superseded to 712-3004A)

$3.99

$

In Stock, Qty 20+

0

92

Cub Cadet 1770205

Drive Pin, 5/16 x 1

$

$

Not available

95

Cub Cadet 1756151

Idler Pulley

$48.99

$

Usually ships in 3-6 days

0

96

Cub Cadet 1760096

Belt Guide

$

$

Not available

97

Cub Cadet 1760097

Idler Pulley

$

$

Not available

98

Cub Cadet 1751848

Swivel

$

$

Not available

99

Cub Cadet 1772460

Clutch Rod

$

$

Not available

100

Cub Cadet 1771514

Brake Lock Latch

$

$

Not available

101

Cub Cadet 1765156

Clip, 3/4

$

$

Not available

102

Cub Cadet 1765167

Brake Pedal Pad

$

$

Not available

103

Cub Cadet 1772741

Brake Pedal

$

$

Not available

104

Cub Cadet 1765257

Brake Lock Bracket

$

$

Not available

105

Cub Cadet 1765297

Parking Brake Pedal Pad

$

$

Not available

106

Cub Cadet 1765305

Compression Spring

$

$

Not available

107

Cub Cadet 1985140

Extension Spring

$

$

Not available

108

Cub Cadet 1765402

Extension Spring

$33.99

$

Usually ships in 3-6 days

0

109

Cub Cadet 1765461

Pivot Rod

$

$

Not available

110

Cub Cadet 1766215

Hub Cap

$

$

Not available

111

Cub Cadet 1773176

Spring

$

$

Not available

113

Cub Cadet 1118808

Retaining Ring, 5/8

$

$

Not available

122

Cub Cadet 1186393

Flange Nut, 3/8-16

$3.49

$

In Stock, only 2 left!

0

134

Cub Cadet 1765064

Idler Arm Assembly

$

$

Not available

139

Cub Cadet 1890945

Flat Washer, 3/8
(Superseded to 936-0140)

$

$

Not available

142

Cub Cadet 1767808

Belt Guide

$

$

Not available

147

Cub Cadet 1772391

Transaxle, Peerless MST-205 5-Speed

Note: (see "Peerless MST 205 Transaxle Assembly" Illustration & Parts List for breakdown.)

$

$

Not available

150

Cub Cadet 1767895

Brake Rod

$

$

Not available

154

Cub Cadet 1766025

Clutch Retainer

$

$

Not available

160

Cub Cadet 1766200

Engine Sheave

$

$

Not available

163

Cub Cadet 1186231

Hex Nut, 3/8-16
(Superseded to 912-3017)

$4.49

$

In Stock, Qty 20+

0

164

Cub Cadet 1767900

Belt Guide

$

$

Not available

167

Cub Cadet 1100243

Lock Washer, 3/8
(Superseded to 936-0169)

$3.99

$

In Stock, Qty 20+

0

171

Cub Cadet 1104335

Square Key, 3/16
(Superseded to 714-0139)

$9.49

$

Usually ships in 3-6 days

0

174

Cub Cadet 1111683

Hex Screw, 1/4-28 x 1/2
(Superseded to 710-0230)

$

$

Not available

175

Cub Cadet 1185388

Retaining E-Ring, 5/8
(Superseded to 916-0231)

$

$

Not available

176

Cub Cadet 1747998

Flat Washer, 3/4 x 1-7/8

$

$

Not available

187

Cub Cadet 1772728

Brake Pedal Assembly

$

$

Not available

192

Cub Cadet 1891733

Flat Washer
(Superseded to 936-0206)

$4.49

$

In Stock, only 3 left!

0

193

Cub Cadet 1104436

Woodruff Key, 3/16 x 3/4
(Superseded to 914-0868)

$3.99

$

In Stock, only 4 left!

0

195

Cub Cadet 1770294

Shift Shaft Arm

$

$

Not available

200

Cub Cadet 1724491

Flange Lock screw, 5/16-18 x 3/4
(Superseded to 710-1260A)

$3.99

$

In Stock, Qty 20+

0

201

Cub Cadet 603-0638

Gear Shift Arm

$

$

Not available

208

Cub Cadet 1770298

Carriage Bolt, 3/8-16 x 2-1/4

$

$

Not available

209

Cub Cadet 1766115

Knob

$

$

Not available

210

Cub Cadet 1767884

Extension Spring

$

$

Not available

215

Cub Cadet 1766345

Spacer

$

$

Not available

218

Cub Cadet 1766186

Transmission Arm

$

$

Not available

220

Cub Cadet 1770602

Adjusting Rod

$

$

Not available

221

Cub Cadet 1767894

Transmission Support

$

$

Not available

222

Cub Cadet 1765300

V-Belt

$84.99

$

Usually ships in 3-6 days

0

223

Cub Cadet 1770629

Transmission Sheave

$

$

Not available

225

Cub Cadet 1100047

Screw, 3/8-16 x 1-1/4
(Superseded to 710-0520)

$4.49

$

In Stock, Qty 6

0

228

Cub Cadet 1713803

Idler Pulley
(Superseded to 956-3054)

$52.99

$

In Stock, only 2 left!

0

229

Cub Cadet 1772829

Shaft Guide

$

$

Not available

238

Cub Cadet 1767892

Belt Guide

$

$

Not available

272

Cub Cadet 1701055

Special Washer, 3/8

$6.49

$

Usually ships in 3-6 days

0

286

Cub Cadet 1768818

Flat Washer
(Superseded to 736-0262)

$3.99

$

Usually ships in 3-6 days

0

299

Cub Cadet 1729780

Belt Guide

$

$

Not available

309

Cub Cadet 1747738

J-Clamp

$

$

Not available

330

Cub Cadet 1756164

Idler Sheave

$

$

Not available

336

Cub Cadet 1186132

Carriage Bolt, 3/8-16 x 1-3/4
(Superseded to 710-0560)

$6.99

$

In Stock, Qty 12

0

340

Cub Cadet 1767899

Stop

$

$

Not available

386

Cub Cadet 1107385

Flat Washer, 1/2
(Superseded to 936-0326)

$4.49

$

In Stock, only 4 left!

0

390

Cub Cadet 1705108

Flat Washer, 3/8
(Superseded to 936-0117)

$7.49

$

In Stock, only 1 left!

0

518

Cub Cadet 1772455

Tire, 20 x 8.00-8
(Superseded to 734-1730-0901)

$99.99

$

In Stock, only 1 left!

0

519

Cub Cadet 734-3198

Rim, 10.0 x 6.0

$

$

Currently unavailable

520

Cub Cadet 1718086

Valve Stem
(Superseded to 934-0255)

$4.49

$

In Stock, Qty 20+

0

521

Cub Cadet 634-3035

Wheel Assembly Complete

Note: (Includes Ref. 518, 519, & 520.)

$

$

Not available
