12A802-0814-01 - Briggs & Stratton Vertical Engine Head Parts Diagram

Vertical Engine

Head Parts Diagram

  • Title

25

Briggs & Stratton 493262

Piston Assembly (Standard)

$74.99

$

Usually ships in 2-12 days

0

25

Briggs & Stratton 493385

Piston Assembly (.010" O.S.)

$62.99

$

Usually ships in 2-12 days

0

25

Briggs & Stratton 493386

Piston Assembly (.020" O.S.)

$

$

Not available

25

Briggs & Stratton 493387

Piston Assembly (.030" O.S.)

$62.99

$

Usually ships in 2-12 days

0

25

Briggs & Stratton 499429

Piston Assembly (Standard)
(Superseded to 799063)

$91.99

$

In Stock, only 4 left!

0

25

Briggs & Stratton 499430

Piston Assembly (.010" O.S.)

$39.99

$

Usually ships in 2-12 days

0

25

Briggs & Stratton 499431

Piston Assembly (.020" O.S.)
(Superseded to 799064)

$120.99

$

Usually ships in 2-12 days

0

25

Briggs & Stratton 499432

Piston Assembly (.030" O.S.)

$46.99

$

Usually ships in 2-12 days

0

26

Briggs & Stratton 493261

Ring Set (Standard)

$

$

Not available

26

Briggs & Stratton 493388

Ring Set (.010" O.S.)

$31.99

$

Usually ships in 2-12 days

0

26

Briggs & Stratton 493389

Ring Set (.020" O.S.)

$

$

Not available

26

Briggs & Stratton 493390

Ring Set (.030" O.S.)

$29.99

$

Usually ships in 2-12 days

0

26

Briggs & Stratton 499425

Ring Set (Standard)

$

$

Not available

26

Briggs & Stratton 499426

Ring Set (.010" O.S.)

$20.99

$

Usually ships in 2-12 days

0

26

Briggs & Stratton 499427

Ring Set (.020" O.S.)

$52.99

$

Usually ships in 2-12 days

0

26

Briggs & Stratton 499428

Ring Set (.030" O.S.)

$29.99

$

Usually ships in 2-12 days

0

27

Briggs & Stratton 26026

Lock-Piston Pin
(Superseded to 691588)

$4.99

$

In Stock, only 2 left!

0

27

Briggs & Stratton 263190

Lock-Piston Pin
(Superseded to 691866)

$4.49

$

In Stock, Qty 8

0

28

Briggs & Stratton 298908

Pin-Piston (.005" O.S.)

$4.99

$

Usually ships in 2-12 days

0

28

Briggs & Stratton 298909

Pin-Piston

$8.99

$

In Stock, only 2 left!

0

28

Briggs & Stratton 499423

Pin-Piston (Standard)

$9.49

$

Usually ships in 2-12 days

0

29

Briggs & Stratton 490566

Rod-Connecting (Standard)

$39.99

$

Usually ships in 2-12 days

0

29

Briggs & Stratton 490743

Rod-Connecting (.020" Undersize)

$13.99

$

Usually ships in 2-12 days

0

29

Briggs & Stratton 499424

Rod-Connecting (Standard)
(Superseded to 590406)

$87.99

$

In Stock, only 1 left!

0

32

Briggs & Stratton 94699

Screw
(Superseded to 691664)

$4.49

$

In Stock, only 2 left!

0
