128 CD (545192139) - Husqvarna String Trimmer (2009-08) Handle & Controls Parts Diagram

String Trimmer

Handle & Controls Parts Diagram

  • Title

1

Husqvarna 545125301

Assy-Cable/Wire Harness

$37.99

$

In Stock, only 3 left!

0

2

Husqvarna 545066001

Trigger

$

$

Not available

3

Husqvarna 545062001

Housing-Throttle

Note: (RH)

$

$

Not available

4

Husqvarna 530016448

Screw

$6.49

$

In Stock, only 4 left!

0

5

Husqvarna 530016449

Screw

$6.49

$

In Stock, only 2 left!

0

6

Husqvarna 530016454

Spring-Trigger

$6.49

$

In Stock, Qty 7

0

7

Husqvarna 530059804

Lockout-Throttle

$

$

Not available

8

Husqvarna 545045601

Spring-Lockout

$6.49

$

Usually ships in 3-10 days

0

9

Husqvarna 545067001

Housing-Throttle

Note: (LH)

$

$

Not available

10

Husqvarna 545030601

Kit-Switch
(Superseded to 545049301)

$10.99

$

In Stock, Qty 10

0

11

Husqvarna 545042201

Handle - Assist

$17.99

$

Usually ships in 3-10 days

0

12

Husqvarna 530015820

Bolt

$4.99

$

In Stock, only 1 left!

0

13

Husqvarna 545003379

Kit-Driveshaft Upper
(Superseded to 575262501)

Note: (Incl. 16, & flex)

$47.99

$

In Stock, only 2 left!

0

14

Husqvarna 530059185

Clamp - Assist Handle

$6.49

$

In Stock, only 1 left!

0

15

Husqvarna 530016152

Wingnut
(Superseded to 530401992)

$2.49

$

In Stock, only 1 left!

0

16

Husqvarna 530016344

Screw

$

$

Not available

17

Husqvarna 545180847

Kit-Lower Shaft

Note: (Incl. flex)

$56.99

$

Usually ships in 3-10 days

0

18

Husqvarna 545031101

Kit-Shield

Note: (Incl. 19,20,21,22)

$31.99

$

Usually ships in 3-10 days

0

19

Husqvarna 530052287

Limiter - Line

$4.99

$

In Stock, only 2 left!

0

20

Husqvarna 530015814

Screw

$6.49

$

In Stock, Qty 16

0

21

Husqvarna 530015820

Bolt

$4.99

$

In Stock, only 1 left!

0

22

Husqvarna 530016152

Wingnut
(Superseded to 530401992)

$2.49

$

In Stock, only 1 left!

0

23

Dust Cup

$

$

Not available

24

Head - Cutting

$

$

Not available

Husqvarna 545186844

Manual

Note: Not Shown

$3.99

$

Usually ships in 3-10 days

0

Husqvarna 530031159

Wrench-Hex (5/32")

Note: Not Shown

$4.99

$

In Stock, only 1 left!

0
