12533 GC (31AH9776897) - Columbia 33" Snow Thrower (2014) Auger & Shave Plate Parts Diagram

33" Snow Thrower

Auger & Shave Plate Parts Diagram

  • Title
1

MTD 918-04514

Gear Assy-Auger

$543.99

$

Usually ships in 3-6 days

0

2

MTD 684-04151-0637

Spiral Asm:LH 900

$261.99

$

Usually ships in 3-6 days

0

3

MTD 684-04152-0637

Spiral Asm:RH 900

$261.99

$

Usually ships in 3-6 days

0

4

MTD 684-04222-0606

Housing Assy-Auger

$438.99

$

Usually ships in 3-6 days

0

5

MTD 714-04040

Pin-Cotter

$1.49

$

In Stock, Qty 20+

0

6

MTD 731-05162

Spacer: 1.50 Od X

$7.49

$

Usually ships in 3-6 days

0

7

MTD 731-05163

Spacer: 1.50 Od X

$7.49

$

In Stock, Qty 20+

0

8

MTD 937-3000

Grease Fitting

$4.99

$

In Stock, Qty 20+

0

9

MTD 734-04155

Wheel:Deck:5.0 Dia B

$20.99

$

In Stock, Qty 20+

0

10

MTD 938-04158

Axle:Sprl:32.12

$186.99

$

Usually ships in 3-6 days

0

11

MTD 741-0494

Bushing

$3.99

$

In Stock, Qty 20+

0

12

MTD 784-0315A-0637

Housing:Bearing

$

$

Not available

13

MTD 784-5714B-0606

Plate-Shave 33"
(Superseded to 784-5714B-0637)

$55.99

$

In Stock, only 3 left!

0
