11A-109Q897 - Columbia 20" Walk-Behind Mower (2010) General Assembly Parts Diagram

20" Walk-Behind Mower

General Assembly Parts Diagram

  • Title

1

MTD 747-1161A-0637

Blade Control Handle

$13.99

$

In Stock, only 1 left!

0

2

MTD 731-2626

Deluxe Cover - Black

$11.99

$

In Stock, only 2 left!

0

3

MTD 987-02338

Pivot Arm LH

$17.99

$

Usually ships in 3-6 days

0

4

MTD 987-02075B

Hgt. Adjust Ass’y LH

$35.99

$

In Stock, only 2 left!

0

5

MTD 987-02074B

Hgt. Adjust Ass’y RH

$40.99

$

In Stock, only 2 left!

0

6

MTD 987-02337

Pivot Arm RH

$17.99

$

In Stock, only 1 left!

0

7

MTD 710-1205

Rope Guide Bolt

$3.99

$

In Stock, Qty 20+

0

8

MTD 710-1174

Carriage Bolt 5/16-18 x 2.0

$7.49

$

In Stock, Qty 20+

0

9

MTD 749-0928A

Lower Handle
(Superseded to 749-0928A-0637)

Variations

MTD 749-0928A-0637

Lower Handle - POWDER BLACK (0637)

$33.99

$

In Stock, only 2 left!

0

$33.99

$

In Stock, only 2 left!

0

10

MTD 720-0279

Knob - ERS Guide 1/4-20

$4.49

$

In Stock, Qty 20+

0

11

MTD 720-04072A

Knob - Star 5/16-18

$6.99

$

In Stock, Qty 20+

0

12

MTD 914-0104

Int. Cotter Pin .072 x 1.13" Lg.
(Superseded to 714-0104)

$4.49

$

In Stock, Qty 20+

0

13

MTD 946-0957

Control Cable 37.25 " Lg. (Honda)

$17.99

$

In Stock, Qty 20+

0

14

MTD 749-1092A-0637

Upper Handle

$48.99

$

In Stock, only 1 left!

0

15

MTD 926-0240

Cable Tie
(Superseded to 725-0157)

$3.99

$

In Stock, Qty 20+

0

16

MTD 731-06952

Rear Flap

$15.99

$

In Stock, Qty 17

0

17

MTD 732-04631A

Hinge Clip

$4.49

$

Usually ships in 3-6 days

0

18

MTD 682-0139-0606

Deck Assembly

$

$

Not available

19

MTD 987-02107A

Rear Hgt. Adjust Ass’y LH

$45.99

$

In Stock, only 3 left!

0

20

MTD 720-0426

Knob
(Superseded to 731-13116-1)

$13.99

$

In Stock, only 1 left!

0

21

MTD 94832

Spring Lever

$10.99

$

In Stock, only 3 left!

0

22

MTD 734-2004A

Wheel Ass'y 8" x 2.125" Idle BB
(Superseded to 753-08093)

$45.99

$

In Stock, Qty 5

0

23

MTD 936-0504

Wave Washer .51" ID (w/bb wheels)

$4.49

$

In Stock, Qty 9

0

24

MTD 987-02106A

Rear Hgt. Adjust Ass’y RH

$52.99

$

Usually ships in 3-6 days

0

25

MTD 731-07001

Hub Cap - Grey (optional)

$5.49

$

In Stock, only 2 left!

0

26

MTD 738-04266

Shoulder Screw .50 Dia. x .385

$6.49

$

Usually ships in 3-6 days

0

27

MTD 687-02180-0637

Adjust/Brkt. Ass’y RH

$60.99

$

Usually ships in 3-6 days

0

28

MTD 687-02179-0637

Adjust/Brkt. Ass’y LH

$63.99

$

Usually ships in 3-6 days

0

30

MTD 932-0731

Torsion Spring

$10.99

$

Usually ships in 3-6 days

0

32

MTD 782-7006

Hinged Adapter

Variations

MTD 782-7006-0637

BRACKET-MOUNTING H - POWDER BLACK (0637)

$32.99

$

Usually ships in 3-6 days

0

$32.99

$

Usually ships in 3-6 days

0

33

MTD 736-0270

Cupped Washer .265 ID x .75 OD

$3.99

$

In Stock, Qty 20+

0

34

MTD 710-0599

Hex Wash S-Tapp Scr 1/4-20 x .50

$4.49

$

In Stock, Qty 20+

0

35

MTD 710-0654A

Hex Wash HD Tap Scr 3/8-16 x .88

$4.49

$

In Stock, only 4 left!

0

36

MTD 731-1409B

Chute Deflector

$28.99

$

In Stock, Qty 5

0

37

MTD 682-7002

Mulching Plug

$

$

Not available

38

MTD 712-04065

Flanged Lock Nut 3/8-16 Gr. F

$3.99

$

In Stock, Qty 20+

0

39

MTD 787-01290A

Height Adjuster Plate

$12.99

$

In Stock, only 2 left!

0
