1150-1 - Generac COMPANION 5,000 Watt Portable Generator Carburetor (Tecumseh Engine - 143.981007) Parts Diagram

COMPANION 5,000 Watt Portable Generator

Carburetor (Tecumseh Engine - 143.981007) Parts Diagram

  • Title

Briggs & Stratton 640129

Carburetor

Note: (Incl. 184 of Engine Parts List)

$

$

Currently unavailable

1

Briggs & Stratton 631776A

Throttle Shaft & Lever Assembly

$

$

Currently unavailable

2

Briggs & Stratton 631970

Throttle Return Spring

$

$

Currently unavailable

4

Briggs & Stratton 631184

Dust Seal Washer

$

$

Currently unavailable

5

Briggs & Stratton 631183

Dust Seal (Throttle)

$

$

Currently unavailable

6

Briggs & Stratton 640109

Throttle Shutter

$

$

Currently unavailable

7

Briggs & Stratton 650506

Shutter Screw

$

$

Currently unavailable

10

Briggs & Stratton 632597

Choke Shaft and Lever Assembly

$

$

Currently unavailable

11

Briggs & Stratton 632043

Choke Return Spring

$

$

Currently unavailable

12

Briggs & Stratton 631184

Dust Seal Washer

$

$

Currently unavailable

13

Briggs & Stratton 631183

Dust Seal (Choke)

$

$

Currently unavailable

14

Briggs & Stratton 631753

Choke Shutter

$

$

Currently unavailable

15

Briggs & Stratton 630735

Choke Positioning Spring

$

$

Currently unavailable

16

$

$

Currently unavailable

17

Briggs & Stratton 651025

Throttle Crack Screw/Idle Speed Screw

$

$

Currently unavailable

18

Briggs & Stratton 630766

Tension Spring

$

$

Currently unavailable

20

Briggs & Stratton 640027

Idle Restrictor Screw

$

$

Currently unavailable

20A

Briggs & Stratton 640053

Idle Restrictor Screw Cap

$

$

Currently unavailable

25

$

$

Currently unavailable

27

$

$

Currently unavailable

$

$

Currently unavailable

29

Briggs & Stratton 631028

Float Bowl "O" Ring

$

$

Currently unavailable

30

Briggs & Stratton 631021

Inlet Needle, Seat & Clip

Note: (Incl. 31)

$

$

Currently unavailable

31

$

$

Currently unavailable

36

Briggs & Stratton 640113

Main Nozzle Tube

$

$

Currently unavailable

37

Briggs & Stratton 632547

"O" Ring, Main Nozzle Tube

$

$

Currently unavailable

40

Briggs & Stratton 640114

High Speed Bowl Nut

$

$

Currently unavailable

44

Briggs & Stratton 27110

Bowl Nut Washer
(Superseded to 7027110YP)

$11.99

$

Usually ships in 2-12 days

0

47

Briggs & Stratton 630748

Welch Plug, Idle Mixture Well

$

$

Currently unavailable

48

Briggs & Stratton 631027

Welch Plug, Atmospheric Vent

$

$

Currently unavailable
