Troy-Bilt 10056 - Troy-Bilt Horse III Rear-Tine Tiller (SN: 640000 - 855638) Wheel Speed Lever, Belt Drive System, Engines, Wheels Parts Lookup with Diagrams

1

Troy-Bilt GW-9362

PIN - spring, 1/8" dia., retains castle nut to threaded stud

$4.49

$

Usually ships in 3-6 days

2

Troy-Bilt GW-9838

NUT-castle (slotted), 1/2"-20.

$

Not available 

3

Troy-Bilt GW-9934

WASHER- shoulder, 1/2" (shoulder faces disc washers)

$15.99

$

In Stock, only 1 left!

4

Troy-Bilt GW-9932

WASHER- disc spring (concave surfaces face each other)

$24.99

$

In Stock, only 3 left!

5

Troy-Bilt GW-2628

LEVER - wheel speed shift

Note: (Includes #2244 knob (Ref. #8) and 199120 retaining ring (Ref. #18))

$142.99

$

Usually ships in 3-6 days

6

Troy-Bilt 1902240

KNOB - wheel speed shift lever

Note: (Includes #9120 retaining ring (Ref. 1118) and plastic decal inlay)

$23.99

$

In Stock, only 2 left!

7

Troy-Bilt GW-9317

PIN - cotter, 3/32" x 1"

$3.99

$

Usually ships in 3-6 days

8

Troy-Bilt GW-1231

ROD - connecting rod, wheel speed shift lever

$16.99

$

Usually ships in 3-6 days

9

Troy-Bilt GW-1033

SWIVEL - connecting rod

$15.99

$

Usually ships in 3-6 days

10

Troy-Bilt 736-0567

WASHER - flat, 5/16",S.A.E.

$3.49

$

Usually ships in 3-6 days

11

Troy-Bilt 714-04048

PIN - hair cotter

$8.49

$

In Stock, only 2 left!

12

Troy-Bilt n/a

LOCKNUT-hex. hd., 5/16"-18, retains swivel to eccentric lever

$

Currently unavailable 

13

Troy-Bilt 710-0514

BOLT - hex. hd., 3/8"-16 x 1"

$4.49

$

In Stock, Qty 20+

14

Troy-Bilt 936-0169

LOCKWASHER - springlock, 3/8"

(Superseded to 736-0169) 

$3.99

$

In Stock, Qty 20+

15

Troy-Bilt 736-3050

WASHER - flat, 3/8", S.A.E. 9903

$4.49

$

In Stock, Qty 16

16

Troy-Bilt GW-2146

BUSHING - spacer, 21/64" (.325") long, yoke to engine mount

$6.49

$

In Stock, only 4 left!

17

Troy-Bilt GW-1113-1099

BUSHING - spacer, 19/64" (.300") long, yoke link to retaining plug

$5.49

$

In Stock, Qty 20+

18

Troy-Bilt GW-9120

RING - retaining (tolerance ring)

$6.99

$

In Stock, only 1 left!

19

Troy-Bilt GW-1920

BLOCK - belt adjustment, 3-7/8" long

Note: (Includes mounting hardware and belt adjustment rod (Ref. #'s 13,14,15, & 20))

$60.99

$

In Stock, only 1 left!

20

Troy-Bilt GW-2100

ROD - belt adjustment, 7" long, with measuring gauge

$12.99

$

In Stock, only 1 left!

21

Troy-Bilt 1100012

BOLT - hex. hd., 3/8"-24 x 1-3/4", engine pulley

(Superseded to 710-0539) 

$4.99

$

In Stock, Qty 11

22

Troy-Bilt 710-0459A

BOLT - hex. hd., 3/8"-24 x 1-1/2", engine pulley

Note: (For Kohler and Briggs & Stratton Engines)

$6.99

$

In Stock, Qty 8

23

Troy-Bilt GW-1919

DISC-reverse, rubber rimmed

Note: (Includes #1920 belt adjustment block (Ref.#19))

$104.99

$

In Stock, Qty 15

Troy-Bilt 756-04171

DISC ONLY-reverse, rubber rimmed

$67.99

$

In Stock, Qty 15

24

Troy-Bilt GW-9245

BELT -forward drive

$23.99

$

In Stock, Qty 20+

25

Troy-Bilt 619-04124

PULLEY- engine P.T.O. (Power Take Off)

$153.99

$

In Stock, only 2 left!

26

Troy-Bilt 736-04187

SHIM - engine pulley, 1/16" thick

$4.99

$

In Stock, Qty 20+

26

Troy-Bilt 736-04192

SHIM - same as above, 1/32" thick

$6.99

$

In Stock, only 2 left!

27

Troy-Bilt GW-9303

KEY - engine pulley, 3/16" square x 2-1/2"

$3.99

$

In Stock, Qty 10

28

Troy-Bilt 710-0376

BOLT -hex. hd., 5/16"-18 x 1", Grades. Retains engine mounting bar

Note: (ENGINES AND ENGINE MOUNT)

$3.99

$

In Stock, Qty 5

29

Troy-Bilt 912-3010

NUT -hex., 5/16"-18 (jam nut)

(Superseded to 712-3010) 

Note: (ENGINES AND ENGINE MOUNT)

$4.49

$

In Stock, Qty 20+

30

Troy-Bilt GW-1034A

BAR- engine mounting

Note: (ENGINES AND ENGINE MOUNT)

$46.99

$

In Stock, Qty 5

31

Troy-Bilt GW-9147

PLUG - thread protector, red plastic

Note: (ENGINES AND ENGINE MOUNT)

$8.49

$

In Stock, only 1 left!

32

Troy-Bilt 710-0672

BOLT- hex. hd., 5/16"-24 x 1-1/8", engine mounting

Note: (ENGINES AND ENGINE MOUNT)

$4.49

$

In Stock, Qty 18

33

Troy-Bilt 936-0119

LOCKWASHER-springlock, 5/16"

Note: (ENGINES AND ENGINE MOUNT)

$4.99

$

In Stock, Qty 20+

34

Troy-Bilt GW-1968

MOUNT- engine to tiller

Note: (Includes four #9572 mounting bolts (Ref.#32); ENGINES AND ENGINE MOUNT)

$

Currently unavailable 

35

TECUMSEH ENGINE - 6 HP, recoil start,

Note: (Model HH60, Specification 105126J, solid state electronic ignition, horizontal crankshaft is turned down to 3/4" at PTO end to accept engine pulley; ENGINES AND ENGINE MOUNT)

$

Not available 

35

TECUMSEH ENGINE - 6 HP, electric start,

Note: (Model HH-60, Specification 105127J Same as Part No. 10226 engine, but with electric start.; ENGINES AND ENGINE MOUNT)

$

Not available 

35

7 HP TECUMSEH ENGINE-Recoil start

Note: (Model #HMXL700.132501; ENGINES AND ENGINE MOUNT)

$

Not available 

35

7 HP TECUMSEH ENGINE-Electric start

Note: (Model #HMXL70-132502; ENGINES AND ENGINE MOUNT)

$

Not available 

35

KOHLER ENGINE-8 HP Magnum, recoil start

Note: (Model M8T, Specification P5.301512, solid state electronic ignition, horizontal crankshaft is turned down to 3/4" at PTO end to accept engine pulley; ENGINES AND ENGINE MOUNT)

$

Not available 

35

KOHLER ENGINE - 8 HP Magnum, electric start

Note: (Model MBS, Specification PS-301513. Same as Part No. 10203 engine, but with electric start. For use with tillers already equipped with Key Switch Starting System (GRID D-13); ENGINES AND ENGINE MOUNT)

$

Not available 
