030242-0 - Briggs & Stratton 6,200 Watt Portable Generator Alternator (194087) Parts Diagram

6,200 Watt Portable Generator

Alternator (194087) Parts Diagram

  • Title

1

Briggs & Stratton 209599GS

ADAPTER, Alternator

$35.99

$

In Stock, only 1 left!

0

2

Briggs & Stratton 191876GS

ROTOR

$315.99

$

Usually ships in 2-12 days

0

3

Briggs & Stratton 194006AGS

STATOR

$524.99

$

Usually ships in 2-12 days

0

4

Briggs & Stratton 186060GS

CARRIER, Bearing
(Superseded to 193336GS)

$39.99

$

Usually ships in 2-12 days

0

5

Briggs & Stratton 86308CGS

SCREW

$5.49

$

Usually ships in 2-12 days

0

6

Briggs & Stratton 66386GS

BRUSH ASSEMBLY

$23.99

$

In Stock, Qty 20+

0

7

Briggs & Stratton 66849GS

SCREW, Taptite, M5 - 0.8 x 16

$4.99

$

In Stock, only 1 left!

0

8

Briggs & Stratton 22694GS

CONNECTOR

$5.99

$

In Stock, only 1 left!

0

9

Briggs & Stratton 81917GS

PIN

$3.49

$

Usually ships in 2-12 days

0

10

Briggs & Stratton 193428AGS

WIRE

$3.49

$

Usually ships in 2-12 days

0

11

Briggs & Stratton 205858GS

REGULATOR, Voltage

$107.99

$

In Stock, Qty 20+

0

12

Briggs & Stratton 194274GS

HARNESS, Wiring

$

$

Not available

13

Briggs & Stratton 65791GS

BEARING

$34.99

$

Usually ships in 2-12 days

0
