020296-0 - Troy-Bilt 2,500 PSI Pressure Washer Main Unit Parts Diagram

2,500 PSI Pressure Washer

Main Unit Parts Diagram

  • Title

1

Briggs & Stratton 201366GS

Base, w/Mounts

$195.99

$

Usually ships in 2-12 days

0

2

Briggs & Stratton P199110GS

Handle
(Superseded to 199110BVGS)

$85.99

$

Usually ships in 2-12 days

0

3

Briggs & Stratton 201933GS

Kit, Billboard w/Decals & Clips

$67.99

$

In Stock, only 1 left!

0

3

Briggs & Stratton 195964GS

Clips, Tree

$4.99

$

Usually ships in 2-12 days

0

3

Briggs & Stratton 30809GS

Grommet

$4.49

$

Usually ships in 2-12 days

0

4

Briggs & Stratton 192649GS

Kit, Pump Mounting Hardware

$12.99

$

In Stock, only 1 left!

0

5

Briggs & Stratton B2203GS

Kit, Handle Connector

$5.49

$

In Stock, only 1 left!

0

6

Briggs & Stratton 199735GS

Assy, Pump
(Superseded to 207365GS)

$234.99

$

In Stock, Qty 7

0

7

Briggs & Stratton 23139GS

Key

$4.49

$

Usually ships in 2-12 days

0

8

Briggs & Stratton 194298GS

Valve, Thermal Relief
(Superseded to 208673GS)

$14.99

$

In Stock, Qty 20+

0

9

Briggs & Stratton 190632GS

Kit, Water Inlet

$

$

Not available

10

Briggs & Stratton B2384GS

Filter, Inlet

$4.49

$

In Stock, Qty 15

0

11

Briggs & Stratton 190634GS

Kit, Outlet
(Superseded to 201497GS)

$28.99

$

In Stock, Qty 20+

0

12

Briggs & Stratton 190593GS

Kit, Chemical Injection

$

$

Not available

13

Briggs & Stratton 189971GS

Kit, Chemical Hose

$

$

Not available

14

Briggs & Stratton 192310GS

Kit, Vibration Mount

$9.99

$

In Stock, Qty 11

0

15

Briggs & Stratton 196006GS

Hose
(Superseded to 84006753)

$59.99

$

In Stock, Qty 20+

0

16

Briggs & Stratton 201661GS

Kit, Gun Holder

$36.99

$

Usually ships in 2-12 days

0

17

Briggs & Stratton 201324GS

Kit, Nozzles

$22.99

$

In Stock, only 1 left!

0

17

Briggs & Stratton 198841GS

Nozzle, Soap

$10.99

$

Usually ships in 2-12 days

0

17

Briggs & Stratton 195983AEGS

Nozzle, QC, Red

$10.99

$

Usually ships in 2-12 days

0

17

Briggs & Stratton 195983QGS

Nozzle, QC, Green

$10.99

$

In Stock, only 1 left!

0

18

Briggs & Stratton 192309GS

Kit, Hook, Base

$4.49

$

Usually ships in 2-12 days

0

19

Briggs & Stratton 200595GS

Extension
(Superseded to 706595)

$47.99

$

In Stock, Qty 11

0

20

Briggs & Stratton 199117GS

Gun
(Superseded to 704312)

$93.99

$

In Stock, Qty 7

0

21

Briggs & Stratton 201394GS

Kit, Wheel
(Superseded to 202483GS)

$

$

Not available

21

Briggs & Stratton 203872GS

Axle

$2.99

$

Usually ships in 2-12 days

0

21

Briggs & Stratton 200519GS

Hubcap

$19.99

$

In Stock, only 1 left!

0

21

Briggs & Stratton 192050GS

E-Ring
(Superseded to 703976)

$4.49

$

In Stock, Qty 10

0

900

Engine

Note: Contact Engine Manufacturer

$

$

Not available

900

Briggs & Stratton 201740GS

Manual, Operator’s

Note: Parts Not Illustrated

$14.99

$

Usually ships in 2-12 days

0

900

Briggs & Stratton 194256GS

Kit, Tag/Warning Service
(Superseded to 705752)

Note: Parts Not Illustrated

$3.99

$

Usually ships in 2-12 days

0

900

Briggs & Stratton 194524GS

Decal, Choke

Note: Parts Not Illustrated

$7.49

$

Usually ships in 2-12 days

0

900

Briggs & Stratton BB3061BGS

Oil Bottle
(Superseded to 100005)

Note: Parts Not Illustrated

$8.99

$

In Stock, Qty 20+

0

900

Briggs & Stratton 87815GS

Goggles

Note: Parts Not Illustrated

$12.99

$

Usually ships in 2-12 days

0

900

Briggs & Stratton 6048

Kit, O-Ring
(Superseded to 705001)

Note: Optional Accessories

$18.99

$

In Stock, Qty 20+

0

900

Briggs & Stratton 6039

Pump Saver

Note: Optional Accessories

$12.99

$

In Stock, Qty 20+

0
